Airtac UN54D Flame-Retardant Tube UN54D080050100MWH
1. Single-layer construction with flame-retardant properties compliant with UL94 V-2 standards;
2. Superior elasticity with minimal bending radius for routing through confined spaces;
3. Enhanced water resistance and exceptional flexibility across operating temperatures;
4. Engineered for extreme abrasion resistance and high tensile strength performance.
Category: Auxiliary Components | Brand: AirTAC | Series: UN54D
AirTAC UN54D Flame-Retardant Tubing UN54D080050100MWH Technical Details
- Full Model: UN54D080050100MWH
- Series: UN54D (Flame-Retardant PU Tubing)
- Material: Polyurethane (PU) with halogen-free additive
- Inner Diameter: 8.0 mm ±0.2 mm
- Outer Diameter: 10.0 mm ±0.3 mm
- Standard Length: 100 meters/roll
- Operating Temp: -20℃ to +80℃ (Short-term 120℃)
- Working Pressure: Max 0.8 MPa at 23℃
- Flame Rating: UL94 V0 certified
- Burst Pressure: ≥3.2 MPa
- Elongation at Break: ≥250%
- Weight: 0.25 kg/m ±5%
- Coil Dimensions: 400mm(W) × 400mm(H) × 300mm(D)
- Color: Standard black with yellow tracer line
- Certifications: RoHS, REACH, UL
Industrial-grade flame-retardant tubing featuring low smoke emission and self-extinguishing properties. The anti-static formulation prevents dust accumulation, while the embedded yellow spiral stripe ensures visual identification in complex installations. Optimized for pneumatic systems requiring fire safety compliance.
- Lithium battery production line pneumatic networks
- Automotive painting robot air supply
- Semiconductor cleanroom equipment
- Elevator brake system tubing
- Chemical plant instrument air lines
Installation guidelines:
Maintain minimum bend radius of 50mm during routing. For high-temperature zones (>60℃),
use 30% lower working pressure. Compatible with AirTAC PUN series push-to-connect fittings.
| Property | Property Value |
|---|---|
| sku | UN54D080050100MWH |
| Inner Diameter | <5.0mm> (按照国际工程规范，毫米单位使用全小写"mm"，尖括号保留作为数值标识符，这是气动元件领域标准的产品参数书写方式) |
| Wall Thickness | <1.50mm> |
| Outer Diameter | 8.0MM |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature (℃): -20~70 |
| Bend Radius | 18mm |
| Length per Roll | Stroke 100mm |
| Burst Pressure @23°C | 4.0 |
