Airtac X-APKS Swivel Adjustable 5-Way Adapter X-APKS8
AirTAC X-APKS8 Swivel Joint (Adjustable Five-Way Connector) Specifications
- Model: X-APKS8
- Type: Rotatable multi-positional manifold base
- Material: Anodized aluminum alloy body + PPS resin swivel
- Compatible series: APKS/APKH pneumatic cylinders
- Rotation angle: 360° continuous rotation ±5° axial tilt
- Port size: M5×0.8 (G1/8 equivalent)
- Max working pressure: 1.0 MPa
- Temperature range: -10℃ to 80℃
- Installation torque: 0.3-0.5 N·m (swivel adjustment)
- Weight: 98g ±2g
- Dimensions: 48mm(W) × 36mm(D) × 28mm(H)
- Surface hardness: HV0.3 12±2 (anodized layer)
- Leakage rate: ≤3 bubbles/min (under 0.5 MPa)
Modular manifold base enabling multi-axis alignment correction for pneumatic circuits. Features zero-point clamping mechanism with 12°±1° locking detent positions. The diamond-textured grip surface prevents tool slippage during angular adjustments. Compatible with ISO 15407-1 standard pneumatic ports.
- Multi-station rotary indexing tables
- Tool-changing mechanisms in CNC automation
- Articulated end-effector pneumatic routing
- Compact valve island configurations
- Space-constrained robotic workcells
Installation protocol:
Apply thread sealant (LOCTITE 545) on male threads before assembly.
Perform pressure cycling (3× 0-1MPa) after installation to verify seal integrity.
Max angular adjustment force: 2.5N·m (use torque wrench for final positioning).
| Property | Property Value |
|---|---|
| sku | X-APKS8 |
