Airtac X-EPH External Hex Elbow Connector X-EPH601
AirTAC X-EPH601 Hexagonal Elbow Joint Technical Details
- Model: X-EPH601
- Type: External hexagonal swivel elbow joint
- Thread specification: M5×0.8 (internal/external threads)
- Material: Brass with nickel plating (corrosion-resistant)
- Operating pressure: 0.05–0.8 MPa
- Temperature range: -20℃ to 80℃
- Hex size: 8mm across flats
- Rotation angle: 360° continuous swivel
- Seal type: Double-sealed with NBR O-rings
- Surface roughness: Ra ≤3.2μm
- Weight: 22g ±0.5g
- Dimensions: 40mm(L) × 12mm(D) × 15mm(H)
- Torque resistance: 1.5 Nm max
- Vibration resistance: 10–55Hz, 1.5mm amplitude
Precision-machined pivot joint featuring anti-vibration locking teeth and fluid-optimized internal channels. The 45° angled design enables compact piping layouts while maintaining full rotational adjustment. Nickel coating provides IEC 60068-2-11 compliant salt spray resistance (96hrs).
- Robotic end-effector tool changers
- Multi-axis CNC machine lubrication lines
- Semiconductor wafer handling robots
- Pharmaceutical filling station manifolds
- High-cycle packaging machine actuators
Installation protocol:
Apply 0.3–0.5 Nm torque during assembly. Use PTFE tape on male threads only.
For pulsation-heavy systems, install 30–50mm downstream from shock absorbers.
| Property | Property Value |
|---|---|
| sku | X-EPH601 |
