Airtac ZJ-F-TSAI Sensor Mounting Bracket F-TSAI32E
Category: Magnetic Sensors | Brand: AIRTAC | Series: ZJ-F-TSAI Sensor Bracket Series *Key technical highlights:* - Ferrite core magnetization for stable signal transmission - IP67-rated housing for industrial environments - Compatible with ISO 6431/VDMA cylinder standards - LED status indication (optional in select models) - Operating temperature: -10°C to +60°C
AirTAC ZJ-F-TSAI Series Sensor Bracket F-TSAI32E Technical Details
- Model: F-TSAI32E
- Type: Universal inductive sensor mounting bracket
- Compatible sensor body diameter: Φ12mm (industry standard)
- Material: Aluminum alloy 6063-T5
- Surface treatment: Black anodized oxidation
- Mounting hole spacing: 30±0.2mm (horizontal) × 40±0.2mm (vertical)
- Thread specifications: M5×0.8 mounting threads (4 places)
- Operating temperature: -40℃ to +85℃
- Vibration resistance: 10-55Hz, 1.5mm double amplitude
- Shock resistance: 100m/s² (3 axes)
- Weight: 182±5g
- Dimensions: 72mm(L) × 52mm(W) × 34mm(H)
- Corrosion resistance: 96hrs salt spray test passed
- Electrical insulation: ≥100MΩ (500VDC megger test)
Robust multi-position sensor mounting solution with precision-machined adjustment slots enables ±5mm fine-tuning capability. Features anti-loosening M5 fasteners and integrated cable management grooves. Compatible with NPN/PNP inductive/proximity sensors from major brands including Omron, Sick, and Pepperl+Fuchs.
- CNC machine tool position feedback systems
- Automated conveyor belt object detection
- Robotic arm end effector alignment
- Packaging machine fill-level monitoring
- Elevator door safety interlock systems
Installation guidance:
Apply 0.5-0.8N·m torque during fastener tightening. Use shim washers
when mounting on uneven surfaces. Perform alignment verification
after 24hrs of continuous operation.
