Airtac 100M Solenoid Valve Manifold 100M-6F
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Features centralized air supply ports and unified wiring channels, significantly enhancing system maintainability and simplified troubleshooting;
3、Provides modular flexibility with scalable configuration options, supporting adaptable expansion of connected directional control valves as required;
Category: Solenoid Valve Base , Brand: AIRTAC , Series: 100M
AirTAC 100M-6F Manifold Base Specifications
- Model: 100M-6F (Modular Base for 100 Series Valves)
- Port configuration: 6 stations (sub-base for 6 valves)
- Port thread: PT1/8 (BSPP) or G1/8 (optional)
- Material: Aluminum alloy 6063-T5
- Surface treatment: Anodized (12μm thickness)
- Pressure rating: 0.05–1.0 MPa
- Temperature resistance: -20℃ to 80℃
- Weight: ~320g (without valves)
- Dimensions: 120mm(L) × 30mm(W) × 45mm(H)
- Seal compatibility: NBR/Viton
- Mounting pattern: ISO 15407-1 standard
- Flow capacity: 700 Nl/min (at 0.5MPa)
Modular aluminum manifold designed for building multi-valve pneumatic systems. Features precision-machined air passages with integrated silencer grooves and auto-bleed function. Compatible with 100 series solenoid valves (e.g., 3V1, 4V1). Includes 6 M5 mounting threads for valve fixation.
- Centralized control in pneumatic automation lines
- Multi-cylinder sequencing systems
- Textile machinery air distribution
- Beverage filling station manifolds
- Robotic end-effector control clusters
Installation note:
Use torque-controlled wrench (1.2-1.5N·m) for valve mounting.
Apply thread sealant on end plate screws. Maintain 50mm minimum
clearance below base for tubing access.
- Single/Double solenoid valves: 3V1/4V1-06 series
- Pressure valves: AR-06/IR-06 series
- Flow control valves: AS-06/IS-06 series
| Property | Property Value |
|---|---|
| sku | 100M-6F |
