Airtac 200M Solenoid Valve Base 200M-17F
2、Integrated configuration with centralized air supply/exhaust ports and wiring channels, simplifying troubleshooting and maintenance;
3、Flexible modular design with expandable configuration, allowing seamless addition or rearrangement of connected directional control valves to meet evolving system requirements;
Category: Solenoid Valve Manifold Bases , Brand: AIRTAC , Series: 200M
AirTAC 200M-17F Manifold Base Technical Specifications
- Model: 200M-17F
- Type: Modular valve manifold base (multi-station)
- Port configuration: 1/8" NPT (G1/8 optional)
- Number of stations: 17 positions
- Material: Aluminum alloy (A6063-T5)
- Surface treatment: Anodized finish (12-15μm thickness)
- Pressure rating: 0.15-0.8 MPa (21.7-116 PSI)
- Temperature range: -5℃ to 60℃ (operating fluid)
- Seal material: NBR (Nitrile rubber)
- Compatible valves: 100/200/300 series solenoid valves
- Mounting options: DIN rail (35mm) or direct panel mounting
- Weight: 0.25kg (0.55 lbs)
- Dimensions: 146mm(L) × 34mm(W) × 17mm(H)
- Port spacing: 4.25mm pitch between stations
- Leakage rate: ≤3 bubbles/min (ISO 6952-3 test standard)
High-density manifold base designed for centralized control of multiple pneumatic circuits. Features precision-machined air passages with cross-drilled flow channels (Φ1.5mm) for minimized pressure drop. The modular design allows cascade connection for system expansion. Compatible with ISO 15407-1 standard valves.
- Multi-axis pneumatic actuator control systems
- Automated packaging line sequencing
- Textile machinery cluster valve operations
- Semiconductor handling equipment
- Automotive assembly jig controls
Installation guidelines:
Apply 3-5Nm torque during valve mounting. Use LOCTITE 243 threadlocker
for port connections. Maintain 50mm clearance below base for tubing access.
Requires 5μm air filtration upstream.
| Property | Property Value |
|---|---|
| sku | 200M-17F |
