Airtac 2JS Angle Seat Valve 2JS15015Q50
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
AirTAC 2JS15015Q50 Angle Seat Valve Technical Details
- Model: 2JS15015Q50
- Type: 2-way normally closed (spring return)
- Port connection: G1/2" ISO228 standard
- Operating pressure: 0.15–1.0 MPa
- Medium temperature: -10℃ to 180℃ (with high-temp seals)
- Valve body material: CF8M stainless steel (AISI 316 equivalent)
- Seal material: PTFE/Viton combination
- Voltage options: AC24V/110V/220V ±10%, DC24V
- Protection rating: IP67 (coil)/IP65 (valve)
- Flow coefficient (Cv): 4.2
- Response time: ≤50ms (actuation), ≤80ms (reset)
- Installation orientation: Any (360° rotatable piping)
- Weight: 650g ±3%
- Dimensions: 125mm(L) × 62mm(W) × 92mm(H)
High-flow angle seat valve with thermal-shock resistant design, featuring a 45° flow path for reduced turbulence. The piston-driven mechanism ensures bubble-tight shutoff even with particulate-laden media. Includes manual override and position indicator. Compatible with steam, compressed air, and mildly corrosive fluids (pH 4-10).
- Sterilization systems in food processing lines
- Coolant control in CNC machining centers
- Batch process dosing in pharmaceutical manufacturing
- High-temperature steam lines in chemical plants
- Beverage filling station shut-off control
Installation guidelines:
Always install with actuator facing upward in vertical pipelines.
Use PTFE thread sealant (not tape) for leak-free connections.
Requires 5μm filtration upstream. Cycle rate ≤1200 operations/hour.
| Property | Property Value |
|---|---|
| sku | 2JS15015Q50 |
| Port Size | G1/2 |
| Flow Aperture | <15mm> |
