Airtac 2JS Angle Seat Valve 2JS320-32-Q63
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
AirTAC 2JS320-32-Q63 Angle Seat Valve Specifications
- Model: 2JS320-32-Q63
- Type: 2-way normally open (pneumatic actuation)
- Port size: G1-1/4" (BSPP thread)
- Actuation: Pneumatic pilot control (air-to-close)
- Operating pressure: 0.15–1.0 MPa
- Max working pressure: 16 bar (232 psi)
- Temperature range: -10℃ to 180℃ (with FKM seals)
- Seal material: Standard FKM (Viton®), optional PTFE
- Body material: Stainless steel CF8M (316 equivalent)
- Flow coefficient (Cv): 32
- Response time: ≤0.3s (at 6 bar)
- Weight: 4.8 kg ±2%
- Dimensions: 200mm(L) × 135mm(W) × 165mm(H)
- Connection type: ISO 5211 mounting interface
- Protection rating: IP67 (standard)
- Media compatibility: Steam, water, mild chemicals, compressed air
Heavy-duty angle seat valve designed for high-temperature and high-cycle applications. Features 316 stainless steel construction with precision-machined piston guidance system. The 90° flow path design minimizes pressure drop while handling viscous media. Includes manual override and position indicator.
- Steam sterilization systems in pharmaceutical plants
- Hot water circulation control in food processing
- Chemical dosing systems with aggressive media
- High-pressure cleaning equipment (up to 16 bar)
- Beverage filling line shut-off control
Installation note:
Install with actuator facing upward for optimal drainage.
Use 5-10μm filtered air at 0.5-0.7 MPa for pilot control.
Apply thread sealant only on male threads (PTFE tape not recommended).
| Property | Property Value |
|---|---|
| sku | 2JS320-32-Q63 |
| Port Size | G1-1/4 |
| Flow Aperture | <32 mm> |
