Airtac 2JS Angle Seat Valve 2JSY15010Q50G
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
AirTAC 2JSY15010Q50G Angle Seat Valve Technical Specifications
- Full model: 2JSY15010Q50G
- Valve type: 2-position single-acting angle seat (spring return)
- Port connection: G1/2" ISO228 standard
- Operating pressure: 0.15-1.0 MPa (21.7-145 PSI)
- Temperature range: -10℃ to 180℃ (extended thermal stability version)
- Seal materials: PTFE/Viton® combination (standard), optional Kalrez® for chemical resistance
- Actuation: Pneumatic pilot control with manual override
- Flow coefficient: Kv=4.3 m³/h (Cv=4.8)
- Response time: ≤0.3s (at 0.6 MPa)
- Body material: CNC-machined 6061-T6 aluminum alloy with hard anodizing
- Weight: 1.65 kg (3.64 lbs)
- Dimensions: 145mm(H) × 82mm(W) × 65mm(D)
- Protection class: IP67 (submersible up to 1m for 30min)
- Certifications: RoHS, REACH, ISO 9001:2015
High-performance angle seat valve featuring snap-action piston mechanism for precise flow control in high-temperature and corrosive environments. The 45° seat design enables bubble-tight shut-off with minimal pressure loss. Enhanced with wear-compensating seal technology for extended service life. Requires 40μm filtered compressed air (ISO 8573-1 class 4.4.3) for pilot operation.
- Steam line control in food processing autoclaves
- Chemical dosing systems with aggressive media (acids/alkalis)
- High-temperature water circulation in pharmaceutical CIP/SIP processes
- Beverage filling line shut-off with viscous liquids
- Textile dyeing machine pressure regulation
Installation guidelines:
Mount vertically with flow arrow alignment. For horizontal mounting,
use support bracket (accessory code BR-2JS150). Apply thread sealant
only on male threads, avoiding contamination of sealing surfaces.
Perform 10-15 open/close cycles after installation to seat seals properly.
| Property | Property Value |
|---|---|
| sku | 2JSY15010Q50G |
| Port Size | G3/8 |
| Flow Aperture | <15mm> |
