Airtac 2JS Angle Seat Valve 2JSY15015Q40G
$127.91
Regular price
$135.41
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
2JSY15015Q40G
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Pneumatic-controlled operation enables safe deployment in explosive environments and non-electrical applications. Features low actuation pressure requirements for reliable low-pressure control over high-pressure systems.
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
Installation guidelines:
Mount with flow direction arrow aligned. For steam applications,
install with actuator below horizontal pipe axis to prevent
condensate accumulation. Lubricate threads with PTFE tape only.
Allow 20mm clearance for manual override operation.
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
AirTAC 2JSY15015Q40G Angle Seat Valve Specifications
- Model: 2JSY15015Q40G
- Type: 2-way normally open (pneumatic actuation)
- Port connection: G1/2" (BSPP thread)
- Valve diameter: DN15 (15mm)
- Operating pressure: 0.2–1.0 MPa
- Max working temperature: 180℃ (with FKM seals)
- Actuation pressure: 0.3–0.8 MPa
- Seal material: Standard NBR / Optional FKM/Viton
- Body material: Stainless steel CF8M (316 equivalent)
- Flow coefficient (Cv): 4.2
- Response time: ≤0.3s
- Weight: 1.25kg ±5%
- Dimensions: 160mm(L) × 70mm(W) × 115mm(H)
- Protection rating: IP67 (with proper installation)
- Certifications: RoHS compliant, REACH tested
High-flow angle seat valve with stainless steel construction, designed for aggressive media and high-temperature applications. Features a spring-return actuator with visual position indicator. The 45° seat design minimizes pressure drop while enabling efficient fluid shut-off.
Typical Applications:
- Steam control in food processing lines
- Chemical dosing systems with corrosive liquids
- High-temperature water circulation systems
- Brewery CIP (Clean-in-Place) installations
- Pharmaceutical process automation
Installation guidelines:
Mount with flow direction arrow aligned. For steam applications,
install with actuator below horizontal pipe axis to prevent
condensate accumulation. Lubricate threads with PTFE tape only.
Allow 20mm clearance for manual override operation.
| Property | Property Value |
|---|---|
| sku | 2JSY15015Q40G |
| Port Size | G1/2 |
| Flow Aperture | <15mm> |
