Airtac 2JS Angle Seat Valve 2JSY20020Q40G
$148.85
Regular price
$156.35
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
2JSY20020Q40G
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Pneumatic-controlled operation enables safe deployment in explosive environments and non-electrical applications. Features low actuation pressure requirements for reliable low-pressure control over high-pressure systems.
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
Installation guidelines:
Arrow marking indicates flow direction - must align with process media flow.
For steam applications, install with actuator positioned horizontally to prevent
condensate accumulation. Use PTFE tape on threads with 1.5 turns beyond end.
Requires monthly lubrication of piston rod (food-grade silicone grease).
Critical notes:
Not compatible with glycol-based fluids. Always install downstream filter
(5μm) when handling particulate-containing media. Thermal expansion
compensation required for pipe lengths >2 meters.
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
AirTAC 2JSY20020Q40G Angle Seat Valve Technical Details
- Model: 2JSY20020Q40G
- Type: 2/2-way normally closed (pneumatic actuation)
- Port size: G1" (BSPP thread)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Max flow rate: 2800 l/min (at 7 bar)
- Actuation pressure: ≥0.3 MPa
- Voltage: 24V DC (solenoid coil)
- Power consumption: 2.5W
- Temperature range: -10℃ to 180℃ (medium)/ -20℃ to 60℃ (ambient)
- Seal material: PTFE + EPDM (FDA compliant)
- Body material: CF8M stainless steel (AISI 316 equivalent)
- Weight: 1.45 kg
- Dimensions: 138mm(L) × 102mm(W) × 162mm(H)
- Response time: ≤0.3s
- Protection rating: IP67 (solenoid)
- Certifications: RoHS, REACH, ISO 9001
High-flow angle seat valve with 90° flow path design, optimized for steam and aggressive media handling. Features zero-leakage piston seal technology and thermal shock-resistant construction. Requires compressed air (40-60 PSI) for pneumatic actuation with manual override capability.
Industrial Applications:
- Beverage filling line sterilization systems
- Pharmaceutical CIP/SIP processes
- Textile dyeing machine steam control
- Chemical processing with corrosive liquids
- Food-grade air systems in packaging
Installation guidelines:
Arrow marking indicates flow direction - must align with process media flow.
For steam applications, install with actuator positioned horizontally to prevent
condensate accumulation. Use PTFE tape on threads with 1.5 turns beyond end.
Requires monthly lubrication of piston rod (food-grade silicone grease).
Critical notes:
Not compatible with glycol-based fluids. Always install downstream filter
(5μm) when handling particulate-containing media. Thermal expansion
compensation required for pipe lengths >2 meters.
| Property | Property Value |
|---|---|
| sku | 2JSY20020Q40G |
| Port Size | G3/4 |
| Flow Aperture | <20mm> |
