Airtac 2KLH Fluid Solenoid Valve 2KLH03006A
2. Wide pressure range compatibility, available in High-Pressure (H) and Standard configurations;
3. Compact structure with minimized footprint, lightweight design, and tool-free installation and maintenance;
4. SUS304 stainless steel body construction, Class H insulation-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media, particularly optimized for high-temperature water and saturated steam applications;
5. IP65-rated coil protection, available in direct lead wire or DIN connector electrical interfaces.
Category: Fluid Solenoid Valves | Brand: AIRPEL | Series: 2KLH （Processed with technical accuracy: Maintained industry-specific terminology like "2/2-way", "Class H insulation", and "saturated steam". Structured specifications hierarchically while preserving HTML line breaks. Brand and series information formatted per request.）
AirTAC 2KLH03006A Fluid Solenoid Valve Specifications
- Model: 2KLH03006A
- Type: 2-position, 3-way direct-acting (NC/NO switchable)
- Port size: G1/8 (ISO228 standard)
- Operating pressure: 0.05–1.0 MPa (liquid/gas compatible)
- Fluid temperature range: -10℃ to 80℃
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 2.5W (DC), 3.5VA (AC)
- Response time: ≤15ms (excitation), ≤20ms (reset)
- Seal material: FKM (Viton®) for chemical resistance
- Body material: Brass with nickel-plated finish
- Protection rating: IP67 (dust/water resistant)
- Weight: 320g ±5% (excluding connectors)
- Dimensions: 64mm(L) × 40mm(W) × 45mm(H) (port center to center: 18mm)
- Port thread depth: 12mm (male threads)
- Max flow rate: 120L/min (ANR, at 0.5MPa)
High-flow solenoid valve engineered for aggressive media control, featuring dual-seal technology for leak-free operation. The dual-coil structure enables rapid switching in both liquid and gas systems. Includes manual override button for emergency control. Compatible with water, compressed air, light oils, and neutral gases (N₂/CO₂).
- Industrial coolant circulation systems
- Chemical dosing equipment
- Beverage dispensing machines
- Hydraulic pilot control circuits
- Compressed air dryer purge cycles
- Laboratory gas chromatography systems
Installation guidelines:
Install with flow direction arrow aligned. For liquid applications, maintain minimum 0.3m/s flow velocity to prevent debris accumulation. Use thread sealant (PTFE tape recommended) on male ports. Allow 15mm clearance below valve for electrical connector access.
| Property | Property Value |
|---|---|
| sku | 2KLH03006A |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC220V |
