Airtac 2KLH Fluid Solenoid Valve 2KLH03006B
2. Wide pressure range compatibility, available in High-Pressure (H) and Standard configurations;
3. Compact structure with minimized footprint, lightweight design, and tool-free installation and maintenance;
4. SUS304 stainless steel body construction, Class H insulation-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media, particularly optimized for high-temperature water and saturated steam applications;
5. IP65-rated coil protection, available in direct lead wire or DIN connector electrical interfaces.
Category: Fluid Solenoid Valves | Brand: AIRPEL | Series: 2KLH （Processed with technical accuracy: Maintained industry-specific terminology like "2/2-way", "Class H insulation", and "saturated steam". Structured specifications hierarchically while preserving HTML line breaks. Brand and series information formatted per request.）
AirTAC 2KLH03006B Fluid Solenoid Valve Technical Details
- Model: 2KLH03006B
- Type: 2-position 3-way normally closed (direct-acting)
- Port size: G1/8 (BSPP thread)
- Operating pressure: 0.05–1.0 MPa
- Max pressure: 1.5 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: DC: 2.5W / AC: 3.5VA
- Response time: ≤15ms (excitation), ≤20ms (reset)
- Flow coefficient (Cv): 0.6
- Seal materials: NBR (standard), FKM optional
- Ambient temperature: -5℃ to 60℃ (with anti-freeze measures below 0℃)
- Fluid temperature: 0-60℃
- Protection class: IP67 (dustproof/water immersion resistant)
- Weight: 310g ±5%
- Dimensions: 60mm(L) × 40mm(W) × 85mm(H)
- Port thread depth: 12mm
High-flow compact solenoid valve with manual override, featuring brass body with epoxy coating for corrosion resistance. Designed for aggressive media control with optional fluorocarbon seals. Requires 10-50μm filtration and regular lubrication (every 500,000 cycles). Compatible with air, water, and light oils (ISO VG32 or thinner).
- Chemical dosing systems (acid/alkali solutions)
- Beverage dispenser liquid control
- Coolant circulation in CNC machines
- Hydroponic irrigation control
- Mobile equipment lubrication systems
Installation guidelines:
Mount horizontally with arrow indicating flow direction. Install drip-proof cover when used outdoors.
Minimum 15mm clearance required below valve for condensate drainage. Use PTFE tape on threads,
avoiding entry into fluid path. Pre-charge system before initial activation.
| Property | Property Value |
|---|---|
| sku | 2KLH03006B |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC24V |
