Airtac 2KLH Fluid Solenoid Valve 2KLH03006CI
2. Wide pressure range compatibility, available in High-Pressure (H) and Standard configurations;
3. Compact structure with minimized footprint, lightweight design, and tool-free installation and maintenance;
4. SUS304 stainless steel body construction, Class H insulation-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media, particularly optimized for high-temperature water and saturated steam applications;
5. IP65-rated coil protection, available in direct lead wire or DIN connector electrical interfaces.
Category: Fluid Solenoid Valves | Brand: AIRPEL | Series: 2KLH （Processed with technical accuracy: Maintained industry-specific terminology like "2/2-way", "Class H insulation", and "saturated steam". Structured specifications hierarchically while preserving HTML line breaks. Brand and series information formatted per request.）
AirTAC 2KLH03006CI Fluid Solenoid Valve Technical Details
- Model: 2KLH03006CI
- Type: 2-position 5-way direct acting (double solenoid)
- Port size: PT1/4 (G1/4 optional)
- Fluid compatibility: Air, water, light oil (ISO VG32 or thinner)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC24V (±10%), AC220V (±10% 50/60Hz)
- Power consumption: 3.5W (DC24V), 5.5VA (AC220V)
- Weight: 480g ±5% (without connectors)
- Dimensions: 90mm(L) × 45mm(W) × 85mm(H)
- Seal material: FKM (Fluorocarbon Rubber)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Flow characteristics: Cv=0.65 (Kv=0.57)
- Response time: ≤20ms (at rated voltage)
- Protection rating: IP65 (dust-tight & water jet resistant)
- Port thread depth: 12mm (full thread engagement recommended)
High-flow fluid control valve with dual solenoid operation, featuring corrosion-resistant brass body and hardened stainless steel spool. Designed for aggressive duty cycles (≥5 million operations) with zero-lash pilot mechanism preventing internal leakage. Requires 25μm filtration and automatic drain installation when used with condensable fluids.
- Hydraulic power unit directional control
- Coolant line switching in CNC machining centers
- Lubrication system sequencing
- Beverage dispensing system fluid control
- Plastic injection molding machine hydraulics
Installation protocol:
Mount in vibration-free environment using M5 mounting screws (not included).
Maintain 15° maximum deviation from vertical axis during operation.
Always install downstream moisture separator when handling compressed air.
Voltage note:
For AC models, use noise suppressor (R-C circuit) within 50cm of coil.
DC models require reverse polarity protection circuit for extended lifespan.
| Property | Property Value |
|---|---|
| sku | 2KLH03006CI |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC 110V |
