Airtac 2KLH Fluid Solenoid Valve 2KLH03008FI
2. Wide pressure range compatibility, available in High-Pressure (H) and Standard configurations;
3. Compact structure with minimized footprint, lightweight design, and tool-free installation and maintenance;
4. SUS304 stainless steel body construction, Class H insulation-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media, particularly optimized for high-temperature water and saturated steam applications;
5. IP65-rated coil protection, available in direct lead wire or DIN connector electrical interfaces.
Category: Fluid Solenoid Valves | Brand: AIRPEL | Series: 2KLH （Processed with technical accuracy: Maintained industry-specific terminology like "2/2-way", "Class H insulation", and "saturated steam". Structured specifications hierarchically while preserving HTML line breaks. Brand and series information formatted per request.）
AirTAC 2KLH03008FI Fluid Solenoid Valve Technical Details
- Model: 2KLH03008FI
- Type: 3-position, 5-way (double solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.05–1.0 MPa
- Voltage options: DC24V (±10%), AC220V (±10% 50/60Hz)
- Flow characteristics: Cv=2.2 (Kv=1.9)
- Response time: ≤30ms (energize), ≤50ms (de-energize)
- Weight: 350g ±5% (with coil)
- Dimensions: 80mm(L) × 50mm(W) × 65mm(H)
- Seal material: FKM fluorocarbon rubber
- Temperature range: -10℃ to 150℃ (medium/ambient)
- Power consumption: ≤2.5W (DC), ≤3.5VA (AC)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
- Max operating frequency: 5Hz (with proper lubrication)
High-flow proportional control valve with dual manual override and position-indication LEDs. Features corrosion-resistant aluminum alloy body with brass core components, optimized for aggressive media like compressed air with oil mist or mild chemical vapors. Requires 5μm filtration (ISO 8573-1 class 4).
- Automated production line actuator control
- Food processing pneumatic systems (FDA-compliant grease option)
- Chemical dosing equipment
- High-cycle packaging machinery
- High-temperature hydraulic circuits (with heat shield kit)
Installation guidelines:
Mount in vibration-free environment using M5 mounting screws (max torque 2.5N·m).
Maintain 15mm clearance from adjacent components for heat dissipation.
Use PTFE tape on male threads only, avoiding entry into flow paths.
Critical note:
Not compatible with phosphate ester fluids or strong oxidizers.
When handling glycol-based fluids, replace seals every 2,000 operating hours.
| Property | Property Value |
|---|---|
| sku | 2KLH03008FI |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC12V |
