Airtac 2KLH Fluid Solenoid Valve 2KLH05010E
2. Wide pressure range compatibility, available in High-Pressure (H) and Standard configurations;
3. Compact structure with minimized footprint, lightweight design, and tool-free installation and maintenance;
4. SUS304 stainless steel body construction, Class H insulation-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media, particularly optimized for high-temperature water and saturated steam applications;
5. IP65-rated coil protection, available in direct lead wire or DIN connector electrical interfaces.
Category: Fluid Solenoid Valves | Brand: AIRPEL | Series: 2KLH （Processed with technical accuracy: Maintained industry-specific terminology like "2/2-way", "Class H insulation", and "saturated steam". Structured specifications hierarchically while preserving HTML line breaks. Brand and series information formatted per request.）
AirTAC 2KLH05010E Fluid Solenoid Valve Specifications
- Model: 2KLH05010E
- Type: 2-position 3-way normally closed (direct-acting)
- Port size: PT1/8 (G1/8 optional)
- Fluid compatibility: Water, neutral gases, light oils (pH 6-8)
- Operating pressure: 0.05–1.0 MPa (liquid), 0.15–0.8 MPa (gas)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Weight: 320g ±5% (with coil)
- Dimensions: 60mm(L) × 40mm(W) × 82mm(H) (excluding connections)
- Seal material: EPDM (standard), optional FKM/Viton for chemical resistance
- Temperature range: -10℃ to 80℃ (fluid/media), -20℃ to 50℃ (ambient)
- Power consumption: ≤2.5W (DC), ≤3.5VA (AC)
- Response time: ≤15ms (open), ≤20ms (close)
- Protection rating: IP67 (coil), IP65 (valve body)
- Cycle life: ≥5 million operations (at rated conditions)
High-flow fluid control valve with zero pressure start capability, featuring brass body with electroless nickel plating for corrosion resistance. The direct-acting design ensures reliable operation in low-pressure systems (down to 0.05MPa). Includes manual override and LED status indicator (selectable versions). Compatible with automatic lubrication systems when using oil-compatible seals.
- Water treatment plant chemical dosing systems
- Medical equipment fluid control (dialysis machines, sterilizers)
- Food processing line CIP (Clean-in-Place) circuits
- Semiconductor cooling water distribution
- Industrial dishwasher water flow management
- Hydroponic system nutrient solution control
Installation requirements:
Maintain horizontal piping alignment during installation. Requires 10μm filtration for liquid applications.
For continuous operation, implement duty cycles ≤60% (ON time ≤36 sec/min). Drain valve must be installed
below the unit in liquid systems. Allow 15mm clearance around coil for heat dissipation.
Fluid limitations:
Not compatible with strong acids, alkalis, or fluids containing particles >100μm.
Maximum viscosity: 20mm²/s. Avoid sudden pressure shocks exceeding 1.5MPa.
| Property | Property Value |
|---|---|
| sku | 2KLH05010E |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC24V |
