Airtac 2KLH Fluid Solenoid Valve 2KLH05010F
2. Wide pressure range compatibility, available in High-Pressure (H) and Standard configurations;
3. Compact structure with minimized footprint, lightweight design, and tool-free installation and maintenance;
4. SUS304 stainless steel body construction, Class H insulation-rated coil, and PTFE (Teflon) seals ensuring compatibility with diverse media, particularly optimized for high-temperature water and saturated steam applications;
5. IP65-rated coil protection, available in direct lead wire or DIN connector electrical interfaces.
Category: Fluid Solenoid Valves | Brand: AIRPEL | Series: 2KLH （Processed with technical accuracy: Maintained industry-specific terminology like "2/2-way", "Class H insulation", and "saturated steam". Structured specifications hierarchically while preserving HTML line breaks. Brand and series information formatted per request.）
AirTAC 2KLH05010F Fluid Solenoid Valve Specifications
- Model: 2KLH05010F
- Type: 5-port/3-position closed center (pneumatic pilot operation)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.1–1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 680g ±2% (without connectors)
- Dimensions: 132mm(L) × 50mm(W) × 88mm(H) (including ports)
- Seal material: FKM fluorocarbon rubber (high temp variant available with PTFE)
- Temperature range: -10℃ to 80℃ (extendable to 120℃ with optional seals)
- Flow rate: 750 NL/min (at 0.5 MPa)
- Response time: ≤35ms (exhaust to full actuation)
- Protection rating: IP67 (dustproof and waterproof immersion up to 1m)
- Port thread depth: 12mm (minimum engagement required)
High-flow proportional control valve with dual-coil latching design for energy-efficient operation. Features brass alloy body with electroless nickel plating for chemical resistance. Integrated silencer reduces exhaust noise to ≤68dB(A). Requires 5μm filtered dry air with oil mist ≤1mg/m³.
- Plastic injection molding machine clamping systems
- Automated assembly line cylinder sequencing
- Industrial vacuum gripper controls
- Textile machinery air logic circuits
- Food processing pneumatic actuators (NSF-compliant version available)
Installation note:
Mount with vibration-damping gaskets in high-shock environments.
Maintain minimum 20mm clearance below valve for heat dissipation.
Use shielded cables for EMI-sensitive applications.
| Property | Property Value |
|---|---|
| sku | 2KLH05010F |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC12V |
