Airtac 2KS Series Fluid Control Valve 2KS03006A
2、Wide pressure range compatibility with specialized configurations: Ultra-High Pressure (X), High Pressure (H), Standard, and High Flow (L) variants;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation/maintenance capabilities;
4、SUS304 stainless steel body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with diverse media. Custom sealing materials available through technical consultation;
5、IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KS
AirTAC 2KS Series Fluid Control Valve 2KS03006A Specifications
- Model: 2KS03006A
- Type: 2-position, single solenoid spring return
- Port configuration: 3/2-way normally closed
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.05–1.0 MPa
- Maximum flow rate: 750 L/min (ANR)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: FKM (Fluorocarbon Rubber)
- Ambient temperature range: -5℃ to 80℃ (non-freezing)
- Fluid temperature range: 0℃ to 60℃
- Protection rating: IP67 (dustproof/water immersion resistant)
- Weight: 320g ±5g (including coil)
- Dimensions: 56mm(L) × 34mm(W) × 78mm(H)
- Mounting orientation: Any (recommended vertical)
- Port thread depth: 10mm (minimum engagement)
High-flow proportional control valve with dynamic pressure compensation, featuring a robust anodized aluminum body and corrosion-resistant brass ports. The low-hysteresis design maintains precise flow regulation (±2% repeatability) across varying loads. Integrated surge protection circuitry enhances coil durability in voltage fluctuation environments.
- Pneumatic cylinder speed control in assembly lines
- Vacuum generator regulation in packaging systems
- Medical gas pressure modulation devices
- Automated liquid dispensing systems (compatible with ISO 32 hydraulic oil)
- Semiconductor manufacturing equipment
Installation guidelines:
Use M5 mounting screws with 0.49–0.69N·m torque. Maintain 50mm clearance from heat sources.
Install upstream 5μm filter (with auto-drain). Lubrication: ISO VG32 turbine oil recommended.
Critical note:
Not compatible with phosphate ester-based fluids. Avoid rapid pressure shocks exceeding 1.2MPa.
Cycle rate limited to 5Hz continuous operation.
| Property | Property Value |
|---|---|
| sku | 2KS03006A |
| Port Size | PT1/8 |
| Flow Aperture | PT1/8 |
| Coil Voltage | AC220V |
