Airtac 2KS Series Fluid Control Valve 2KS03008A
2、Wide pressure range compatibility with specialized configurations: Ultra-High Pressure (X), High Pressure (H), Standard, and High Flow (L) variants;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation/maintenance capabilities;
4、SUS304 stainless steel body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with diverse media. Custom sealing materials available through technical consultation;
5、IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KS
AirTAC 2KS Series Fluid Control Valve 2KS03008A Technical Details
- Model: 2KS03008A
- Type: 3-position closed-center directional control valve
- Port configuration: 5 ports (P, A, B, EA, EB)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.1–1.0 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 820g ±2% (with solenoid)
- Dimensions: 58mm(W) × 62mm(H) × 135mm(L)
- Seal materials: HNBR (Hydrogenated Nitrile) + FKM (Fluorocarbon)
- Temperature tolerance: -5℃ to 80℃ (non-freezing)
- Flow capacity: 850 L/min (ANR) at 0.5MPa
- Response time: ≤25ms (exhaust to center position)
- Protection class: IP67 (coil)/IP40 (valve body)
- Manual override: Standard (with lockable toggle)
High-flow proportional control valve with center-block function, featuring dual solenoid operation and metal seal construction. The optimized spool design achieves 30% faster response than previous generation models. Requires 5μm filtered lubricated air (ISO 8573-1 class 3.4.3) with recommended viscosity ISO VG32.
- Plastic injection molding machine clamp control
- Automated production line indexing systems
- Textile machinery tension regulation
- Semiconductor wafer handling robots
- Beverage filling station pressure sequencing
Installation protocol:
Mount on ISO 4401-02-02-0-94 manifold. Maintain ambient humidity below 90% RH.
For horizontal mounting, install exhaust silencers at EA/EB ports. Allow 15mm
clearance below valve for condensate drainage.
| Property | Property Value |
|---|---|
| sku | 2KS03008A |
| Port Size | PT1/4 |
| Flow Aperture | PT1/4 |
| Coil Voltage | AC220V |
