Airtac 2KS Series Fluid Control Valve 2KS05010A
2、Wide pressure range compatibility with specialized configurations: Ultra-High Pressure (X), High Pressure (H), Standard, and High Flow (L) variants;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation/maintenance capabilities;
4、SUS304 stainless steel body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with diverse media. Custom sealing materials available through technical consultation;
5、IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KS
AirTAC 2KS05010A Fluid Control Valve Specifications
- Model: 2KS05010A
- Type: 2-position 3-way normally closed (direct-acting)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.05–1.0 MPa
- Voltage options: DC12V, DC24V, AC110V, AC220V (customizable)
- Weight: 350g ±5%
- Dimensions: 58mm(L) × 42mm(W) × 78mm(H)
- Seal material: FKM fluorocarbon (standard) / EPDM optional
- Temperature range: -10℃ to 80℃ (extended to 120℃ with FKM seals)
- Flow rate: 750 L/min (ANR) at 0.5 MPa
- Response time: ≤15ms (at rated voltage)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (both inlet/outlet)
- Hysteresis: ≤10% of rated voltage
High-flow proportional control valve with integrated pressure compensation, featuring brass body with electroless nickel plating for corrosion resistance. Designed for precise fluid regulation in hydraulic/pneumatic hybrid systems. Requires 25μm filtration and regular lubrication (every 2,000 operating hours).
- Industrial automation liquid dosing systems
- Coolant flow control in CNC machinery
- Hydraulic press pressure sequencing
- Food-grade fluid handling systems (with EPDM seals)
- Water treatment plant chemical injection
Installation note:
Mount horizontally with arrow direction matching flow. Use copper crush washers (not included) for leak-free sealing.
Allow 15-minute run-in period at 0.3MPa before full operation.
Compatibility:
Not suitable for phosphate ester fluids or chlorinated solvents.
Minimum 3-barrel diameter straight piping required upstream.
| Property | Property Value |
|---|---|
| sku | 2KS05010A |
| Port Size | PT3/8 |
| Flow Aperture | PT3/8 |
| Coil Voltage | AC220V |
