Airtac 2KS Series Fluid Control Valve 2KS05010AI
2、Wide pressure range compatibility with specialized configurations: Ultra-High Pressure (X), High Pressure (H), Standard, and High Flow (L) variants;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation/maintenance capabilities;
4、SUS304 stainless steel body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with diverse media. Custom sealing materials available through technical consultation;
5、IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KS
AirTAC 2KS05010AI Fluid Control Valve Specifications
- Model: 2KS05010AI
- Type: 2-position 5-way monostable (solenoid pilot-operated)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.2–1.0 MPa
- Max flow rate: 750 L/min (ANR)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Response time: ≤50ms (exhaust to operation)
- Weight: 680g ±5%
- Dimensions: 58mm(L) × 45mm(W) × 96mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE coating
- Temperature range: -10℃ to 80℃ (non-freezing)
- Protection rating: IP67 (dust-tight and protected against temporary immersion)
- Port thread depth: 12mm (minimum engagement)
- Coil insulation class: Class F (155℃)
The 2KS05010AI features a dual-pressure balanced spool design with triple-layer sealing system, providing exceptional leak resistance in high-vibration environments. Its copper-free aluminum alloy body with hard anodizing treatment ensures corrosion resistance in humid or mildly acidic conditions. The valve incorporates a manual override button and status indicator window for maintenance diagnostics.
- Plastic injection molding machine clamp control
- Automated assembly line cylinder sequencing
- Beverage filling system pneumatic circuits
- Semiconductor wafer handling robotics
- Wastewater treatment plant valve clusters
Installation note:
Mount with vibration-damping gaskets when used in mobile machinery.
Maintain 15° maximum angular deviation from vertical orientation.
Lubricate with ISO VG32 turbine oil if operating below -5℃.
| Property | Property Value |
|---|---|
| sku | 2KS05010AI |
| Port Size | PT3/8 |
| Flow Aperture | PT3/8 |
| Coil Voltage | AC220V |
