Airtac 2KS Series Fluid Control Valve 2KS05010BIG
2、Wide pressure range compatibility with specialized configurations: Ultra-High Pressure (X), High Pressure (H), Standard, and High Flow (L) variants;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation/maintenance capabilities;
4、SUS304 stainless steel body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with diverse media. Custom sealing materials available through technical consultation;
5、IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KS
AirTAC 2KS05010BIG Fluid Control Valve Technical Details
- Model: 2KS05010BIG
- Type: 2-position 5-port pilot-operated directional valve
- Port configuration: 5/2-way (double solenoid)
- Port size: PT1/4 (G1/4 equivalent)
- Thread standard: ISO 228/1 (G-series)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Max flow capacity: 750 NL/min @ 0.5 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Weight: 350g ±5% (including solenoid coils)
- Dimensions: 60mm(L) × 40mm(W) × 80mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) for enhanced oil resistance
- Temperature range: -5℃ to 80℃ (non-freezing conditions)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Response time: ≤30ms (exhaust to full actuation)
- Protection rating: IP67 (coils), IP40 (valve body)
- Expected service life: 50 million cycles (under rated conditions)
High-flow directional control valve with dual electrical feedback options (manual override available). Features copper-free aluminum alloy body with hard anodized treatment for corrosion resistance. Designed for precision bi-directional cylinder control in high-cycling applications. Requires 5μm filtered lubricated air (ISO 8573-1 class 4.4.3).
- Automated production line actuator control
- Plastic injection molding machine clamp systems
- Textile machinery tension control mechanisms
- Automotive welding fixture positioning
- Food processing pneumatic circuits (food-grade grease compatible)
Installation guidelines:
Mount with M4 screws (max torque 1.2N·m). Maintain minimum 20mm clearance
below valve for exhaust flow. Use surge suppressor for DC models in high-vibration
environments. Lubricate monthly with ISO VG32 pneumatic oil if using non-lubricated air.
| Property | Property Value |
|---|---|
| sku | 2KS05010BIG |
| Port Size | PT3/8 |
| Flow Aperture | PT3/8 |
| Coil Voltage | DC24V |
