Airtac 2KS Series Fluid Control Valve 2KS05010CI
2、Wide pressure range compatibility with specialized configurations: Ultra-High Pressure (X), High Pressure (H), Standard, and High Flow (L) variants;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation/maintenance capabilities;
4、SUS304 stainless steel body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with diverse media. Custom sealing materials available through technical consultation;
5、IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KS
AirTAC 2KS05010CI Fluid Control Valve Technical Details
- Model: 2KS05010CI
- Type: 2-position 5-port direct-acting solenoid valve
- Port configuration: 5/2-way (double solenoid)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.1–1.0 MPa
- Maximum flow rate: 750 L/min (Cv=1.3)
- Voltage options: DC12V/24V, AC110V/220V (±10%)
- Power consumption: 1.6W (DC), 2.5VA (AC)
- Seal material: Heat-resistant NBR (Nitrile)
- Body material: Reinforced PBT resin with glass fiber
- Temperature range: -5℃ to 80℃ (non-freezing)
- Response time: ≤15ms (at 0.5MPa)
- Protection rating: IP67 (dust/water resistant)
- Weight: 320g ±5% (with connectors)
- Dimensions: 56mm(L) × 40mm(W) × 72mm(H)
- Port thread depth: 10mm (minimum engagement)
High-speed 5/2-way valve with dual coil operation, featuring rapid response and low hysteresis. The reinforced composite body withstands vibration up to 10Hz/1.5mm amplitude. Includes manual override and position indicator. Requires 5μm filtered air with ISO8573-1:2010 Class 3.4.3 purity standards.
- Pneumatic cylinder sequencing in assembly lines
- Textile machinery double-acting actuator control
- Plastic injection molding machine ejectors
- Automated material handling systems
- Semiconductor wafer transfer robots
Installation protocol:
Mount with M4 screws (torque ≤0.8N·m). Maintain 15mm clearance
below valve for heat dissipation. Use shielded cables for EMI
protection in high-frequency switching applications.
| Property | Property Value |
|---|---|
| sku | 2KS05010CI |
| Port Size | PT3/8 |
| Flow Aperture | PT3/8 |
| Coil Voltage | AC 110V |
