Airtac 2KS Series Fluid Control Valve 2KS05010E
2、Wide pressure range compatibility with specialized configurations: Ultra-High Pressure (X), High Pressure (H), Standard, and High Flow (L) variants;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation/maintenance capabilities;
4、SUS304 stainless steel body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with diverse media. Custom sealing materials available through technical consultation;
5、IP65-rated coil protection with wiring options: direct lead wire or DIN connector interface.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KS
AirTAC 2KS05010E Fluid Control Valve Technical Details
- Model: 2KS05010E (2-Way Normally Closed)
- Port configuration: 2-position, single solenoid
- Port size: G1/4 (BSPP) with ISO228 standard threads
- Operating pressure range: 0.05–0.8 MPa
- Proof pressure: 1.2 MPa (max momentary)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow coefficient (Cv): 1.8 (at 0.5 MPa)
- Response time: ≤15ms (actuation), ≤20ms (release)
- Seal materials: NBR (standard), optional FKM for chemical resistance
- Ambient temperature: -5℃ to 60℃ (no freezing)
- Fluid temperature: 0℃ to 50℃ (air/lubricated)
- Protection class: IP67 (dust/water resistant)
- Weight: 320g ±5% (including coil)
- Dimensions: 58mm(L) × 34mm(W) × 42mm(H) (body only)
- Mounting pattern: 32mm center-to-center screw spacing
High-flow proportional control valve with precision-machined stainless steel spool, optimized for low-pressure pneumatic systems. Features anti-vibration coil design (30m/s² shock resistance) and manual override capability. Requires 5μm filtration (40μm for emergency use). Compatible with ISO VG32 hydraulic oil when using FKM seals.
- Plastic injection molding machine clamp control
- Beverage filling line pressure regulation
- Semiconductor wafer handling vacuum systems
- Hydraulic test bench sequencing
- Agricultural sprayer nozzle control
Installation requirements:
Maintain horizontal piping alignment with arrow markings. Use 0.3-0.5Nm torque
for port fittings. Allow 15mm clearance below valve for condensate drainage.
Lubricate with ISO VG32 oil (1 drop/10 cycles minimum).
| Property | Property Value |
|---|---|
| sku | 2KS05010E |
| Port Size | PT3/8 |
| Flow Aperture | PT3/8 |
| Coil Voltage | AC24V |
