Airtac 2KSH Fluid Control Valve 2KSH03008EI
2. Wide operating pressure range options: Ultra-high pressure (X), High pressure (H), Standard, and High flow (L) variants;
3. Compact structure with small footprint, lightweight design, and tool-free maintenance features;
4. SUS304 stainless steel body construction. Features Class B thermal-rated coil and standard FPM (fluorinated rubber) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5. IP65-rated coil protection. Electrical connection options: Direct lead wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSH
AirTAC 2KSH Fluid Control Valve 2KSH03008EI Technical Details
- Model: 2KSH03008EI
- Type: 3-position, 5-way closed center (Pilot-operated)
- Port size: 1/4" NPT (G1/8 optional)
- Operating pressure: 0.2–1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 350g ±5% (including solenoid)
- Dimensions: 72mm(L) × 42mm(W) × 60mm(H)
- Seal material: FKM fluorocarbon (standard) / EPDM optional
- Temperature range: -10℃ to 80℃ (with FKM seals)
- Power consumption: ≤2.5W (DC), ≤4.5VA (AC)
- Response time: ≤25ms (exhaust to full pressure)
- Flow capacity: 750 Nl/min (Cv=1.2)
- Protection rating: IP67 (solenoid), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional control valve with metal piston design for precise air regulation in industrial automation. Features dual-pressure operation capability and shock-resistant construction. Requires 5μm filtered compressed air with oil mist (ISO 8573-1 Class 3.4.2). Includes manual override and position indicator.
- Pneumatic cylinder sequencing in assembly lines
- Vacuum generator control in material handling systems
- Pressure regulation in plastic injection molding machines
- Automated packaging equipment with multiple actuator control
- Food processing machinery (EPDM seal version)
Installation note:
Mount with vibration-damping brackets in high-cycle applications.
Maintain 15mm clearance below valve for exhaust airflow.
Lubricate pilot valve quarterly with ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | 2KSH03008EI |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC24V |
