Airtac 2KSL Fluid Control Valve 2KSL03006AI
2、Wide pressure range compatibility, available in ultra-high pressure (X), high pressure (H), standard, and large-flow (L) configurations;
3、Compact design with small footprint, lightweight construction, and tool-free assembly/disassembly;
4、SUS304 stainless steel valve body, Class B thermal-rated coil, and standard FPMF (fluororubber) seals compatible with various working media. Custom seal materials available upon consultation with our technical department;
5、IP65-rated coil protection, offering direct lead wire or DIN connector wiring options.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KSL
AirTAC 2KSL Fluid Control Valve 2KSL03006AI Technical Details
- Model: 2KSL03006AI
- Type: 3-position, 5-way closed center (electro-pneumatic)
- Port size: 1/4" NPT (G1/4 optional)
- Operating pressure: 0.05–1.0 MPa (7-145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Max flow rate: 850 L/min (ANR)
- Response time: ≤15ms (exhaust to actuation)
- Weight: 420g ±5% (with connectors)
- Dimensions: 98mm(L) × 54mm(W) × 48mm(H)
- Body material: Anodized aluminum alloy
- Seal material: Heat-resistant FKM fluorocarbon
- Ambient temperature: -10℃ to 80℃ (non-freezing)
- Power consumption: 2.8W (DC24V), 3.5VA (AC220V)
- Protection class: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional control valve with closed-center functionality, engineered for precision pressure regulation in multi-circuit systems. Features dual-coil latching design for energy efficiency and failsafe position memory. The aluminum body with FKM seals enables chemical resistance in harsh environments. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.2.3 air quality.
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- Semiconductor wafer handling robotics
- CNC machine tool pneumatic brakes
- Beverage filling station pressure sequencing
Installation guidelines:
Mount horizontally with exhaust ports downward. Maintain 15mm clearance
for coil heat dissipation. Use anti-vibration washers in high-shock environments.
Lubricate pivot points every 2,000 operating hours with ISO VG32 pneumatic oil.
| Property | Property Value |
|---|---|
| sku | 2KSL03006AI |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
