Airtac 2KWH Fluid Solenoid Valve 2KWH05010FI
2. Extensive pressure range adaptability with model options: Ultra-high pressure (X), High pressure (H), Standard, and Large flow capacity (L);
3. Compact design with minimized footprint, lightweight construction, and tool-free installation for enhanced maintenance efficiency;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer) seals ensure compatibility across diverse media. Customizable seal materials available upon technical consultation;
5. IP65-rated coil protection and multiple wiring configurations: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWH
AirTAC 2KWH05010FI Fluid Solenoid Valve Technical Details
- Model: 2KWH05010FI
- Type: 2-position 3-way normally closed (direct-acting)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure: 0.02–1.0 MPa
- Maximum flow rate: 850 L/min (Cv=1.2)
- Voltage options: DC12V (±10%), DC24V (±10%), AC24V (±10%)
- Power consumption: 2.5W (DC), 3.2VA (AC)
- Weight: 320g ±5g (including coil)
- Dimensions: 63mm(L) × 42mm(W) × 75mm(H)
- Body material: Die-cast aluminum alloy (anodized)
- Seal material: FKM fluoroelastomer (standard), optional EPDM/NBR
- Temperature range: -10℃ to 80℃ (medium temp), -5℃ to 50℃ (ambient)
- Response time: ≤15ms (actuation), ≤20ms (release)
- Protection rating: IP67 (coil), IP65 (valve body)
- Port thread depth: 12mm (minimum engagement)
High-flow solenoid valve featuring corrosion-resistant construction with triple-layer epoxy coating. Engineered for aggressive fluid handling with enhanced dynamic response, integrating a manual override button for system debugging. Requires 10-μm filtration (ISO 4406 16/14/11 class recommended). Compatible with compressed air, inert gases, and water-glycol mixtures (≤30% concentration).
- Pneumatic cylinder control in automated assembly lines
- Coolant flow management in CNC machining centers
- Vacuum/pressure switching in semiconductor manufacturing
- Hydraulic pilot control systems (low-viscosity fluids)
- Beverage dispensing systems with CIP cleaning cycles
Installation guidelines:
Mount with vibration-damping brackets in high-shock environments.
Maintain 15mm clearance below valve for condensate drainage.
Lubricate seals with PAG oil (ISO VG32) during annual maintenance.
Not compatible with:
Chlorinated solvents, ethylene glycol mixtures above 40%,
or media containing particulate >25μm. Avoid rapid pressure
cycling (>2Hz) to prevent diaphragm fatigue.
| Property | Property Value |
|---|---|
| sku | 2KWH05010FI |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC12V |
