Airtac 2KWL Fluid Solenoid Valve 2KWL03008F
2. Wide pressure range adaptability, offering Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) models;
3. Compact design with minimized footprint, reduced weight, and tool-free modular assembly for easy maintenance;
4. Brass valve body, B-class thermal-rated coil, and standard FPMF (Fluorocarbon Rubber) seals compatible with diverse media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection, wiring options include Lead Wire or DIN Connector configurations.
**Category**: Fluid Solenoid Valve | **Brand**: AirTAC | **Series**: 2KWL
AirTAC 2KWL03008F Fluid Solenoid Valve Specifications
- Model: 2KWL03008F
- Type: 2-position, 3-way normally closed (direct-acting)
- Port size: G3/8 (BSPP thread)
- Operating pressure: 0.05–1.0 MPa
- Max pressure: 1.5 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: DC: 6.5W (max), AC: 7.5VA (max)
- Response time: ≤15ms (open/close)
- Seal material: FKM (Fluorocarbon rubber)
- Temperature range: -10℃ to 150℃ (medium), -5℃ to 80℃ (ambient)
- Protection rating: IP67 (dust/water resistant)
- Weight: 480g ±5%
- Dimensions: 98mm(L) × 35mm(W) × 75mm(H)
- Port thread depth: 12mm (male thread)
- Flow coefficient (Cv): 1.8
High-pressure fluid control valve with reinforced stainless steel core and anti-vibration design. Features triple-sealed epoxy-coated coil for chemical resistance. Compatible with water, light oils, and air. Requires 10μm filtration for abrasive media. Optional manual override available (model suffix: /M).
- Industrial coolant circulation systems
- High-pressure cleaning equipment
- Chemical dosing pumps
- Hydraulic test bench controls
- Food-grade liquid transfer systems
- Semiconductor wafer processing tools
Installation note:
Mount horizontally with arrow direction matching flow. Allow 20mm clearance below for drain port access.
Use thread sealant (PTFE tape excluded) for liquid applications. Perform monthly stem lubrication in continuous duty cycles.
| Property | Property Value |
|---|---|
| sku | 2KWL03008F |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC12V |
