Airtac 2P Fluid Control Valve 2P02506BIG
2. Compact design featuring a minimized footprint and lightweight construction for tool-free installation;
3. Nylon 66 valve body paired with Class B insulation solenoid coil and VITON® seals, ensuring broad media compatibility;
4. IP65-rated coil protection and direct lead wire termination for enhanced durability in harsh environments.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2P
AirTAC 2P02506BIG 2-Position Fluid Control Valve Specifications
- Model: 2P02506BIG
- Type: 5-port 2-position (double solenoid, spring return)
- Port configuration: P (pressure), A/B (actuator ports), R/S (exhaust)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.2–0.8 MPa (29–116 psi)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 750 L/min (ANR) at 0.5 MPa
- Effective area: 18 mm² (Cv≈1.0)
- Body material: Aluminum alloy with hard anodized finish
- Seal material: Temperature-resistant NBR (-20℃ to 80℃)
- Response time: ≤30 ms (energized), ≤50 ms (de-energized)
- Weight: 480 g ±5% (including solenoid coils)
- Dimensions: 58mm(L) × 42mm(W) × 78mm(H)
- Protection class: IP67 (coil), IP40 (valve body)
- Max cycling rate: 5 Hz (with clean lubricated air)
High-speed directional control valve optimized for bidirectional pneumatic cylinder operation. Features dual manual override buttons, LED status indicators, and surge-protected coils. The symmetrical port design minimizes pressure drop (ΔP≤0.15MPa at max flow) and enables bi-directional mounting. Requires ISO 8573-1:2010 Class 3 compressed air (max particle size 5μm, oil content ≤1mg/m³).
- Pick-and-place robot end effectors
- Plastic injection molding machine clamp control
- Automated conveyor diverters
- CNC machine tool chuck actuators
- Textile machinery tension control systems
Maintenance protocol:
Lubricate spool monthly with ISO VG32 turbine oil (1-2 drops at pilot ports).
Avoid axial mounting - horizontal orientation preferred for condensate drainage.
| Property | Property Value |
|---|---|
| sku | 2P02506BIG |
| Port Size | G1/8 |
| Flow Aperture | <2.5 mm> |
| Coil Voltage | DC24V |
