Airtac 2P Fluid Control Valve 2P02506EIG
2. Compact design featuring a minimized footprint and lightweight construction for tool-free installation;
3. Nylon 66 valve body paired with Class B insulation solenoid coil and VITON® seals, ensuring broad media compatibility;
4. IP65-rated coil protection and direct lead wire termination for enhanced durability in harsh environments.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2P
AirTAC 2P02506EIG 2-Position Fluid Control Valve Technical Details
- Model: 2P02506EIG
- Type: 5-port 2-position (2P) pneumatic directional valve
- Port configuration: P (pressure), A/B (actuator ports), R/S (exhausts)
- Port size: PT1/4 (G1/4 optional)
- Effective area: 6mm orifice diameter
- Operating pressure: 0.2–0.8 MPa (29–116 PSI)
- Max flow rate: 750 L/min (ANR)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Weight: 320g ±5% (including coil)
- Dimensions: 53mm(W) × 40mm(H) × 124mm(L)
- Seal material: HNBR (Hydrogenated Nitrile) for enhanced oil resistance
- Temperature range: -10℃ to 80℃ (non-freezing)
- Response time: ≤15ms (at 0.5MPa)
- Power consumption: 2.5W (DC), 3.5VA (AC)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
High-flow compact directional valve with metal seal option, featuring dual-pressure operation capability and dust-resistant spool design. The 2P02506EIG utilizes a pilot-operated mechanism with manual override (optional), making it suitable for both automated systems and emergency manual control scenarios. Optimized for vacuum/pressure switching applications with dual exhaust silencers as standard.
- Automated production line clamping/unclamping systems
- Plastic injection molding machine ejectors
- CNC tool changers with dual-pressure requirements
- Packaging machinery vacuum cup arrays
- Lithium battery formation equipment gas circuits
Installation protocol:
Mount using M4 screws (max torque 1.2N·m) with vibration dampening washers.
Maintain ≥15mm clearance below exhaust ports for proper airflow.
Lubrication: ISO VG32 turbine oil mist recommended every 5M cycles.
