Airtac 2S Fluid Control Valve 2S05015CI
2、Direct-acting normally closed 2-position, 2-way solenoid valve with fast response;
3、Compact design with small footprint, lightweight construction, and tool-free installation for easy maintenance;
4、SUS304 stainless steel valve body, B-class heat-resistant electromagnetic coil, standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5、IP65-rated coil protection, electrical connection options: lead wire type or DIN connector.
Category: Fluid Solenoid Valves, Brand: AIRTAC, Series: 2S
AirTAC 2S05015CI Fluid Control Valve Specifications
- Model: 2S05015CI
- Type: 5-port 3-position closed center (Mid-blocking)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.2–0.8 MPa (29–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%)
- Coil power: 1.6W (standard), 2.2W (high-power variant)
- Weight: 680g ±5% (including manifold base)
- Dimensions: 60mm(L) × 54mm(W) × 85mm(H)
- Body material: Anodized aluminum alloy
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature range: -5℃ to 80℃ (with dry air)
- Response time: ≤30ms (at 0.5MPa)
- Flow rate: 750 L/min (ANR) at 0.5MPa
- Protection rating: IP67 (coil), IP40 (valve body)
- Manual override: Built-in push-button with lock
High-flow proportional control valve with mid-position blocking function, featuring low hysteresis and excellent repeatability. The hardened aluminum body with multi-stage filtration compatibility (recommended 5μm filter) ensures durability in high-cycle applications. Electrostatic shielded coil prevents electromagnetic interference in sensitive environments.
- Plastic injection molding machine clamp control
- Automated assembly line positioning systems
- Textile machinery tension regulation
- Food processing pneumatic circuits (oil-free air required)
- Semiconductor handling equipment
Installation note:
Mount on ISO 5599-1 standard manifold using M5 mounting screws (2.5Nm torque limit).
Maintain ambient temperature below 60℃ with ≥50mm clearance from heat sources.
Lubricate using ISO VG32 turbine oil if air line lubrication is used.
| Property | Property Value |
|---|---|
| sku | 2S05015CI |
| Port Size | PT 1/2 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC 110V |
