Airtac 2SH High Pressure Solenoid Valve 2SH03006A
1. Direct-acting normally closed 2-port 2-position configuration, ensuring rapid and sensitive directional switching;
2. Extensive pressure range compatibility with model options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T);
3. Compact structure with minimized dimensions and lightweight design for convenient installation and maintenance;
4. SUS304 stainless steel body construction, B-class thermal-rated solenoid coil. Standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available through our technical department;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2SH
AirTAC 2SH Series High-Pressure Solenoid Valve 2SH03006A Technical Details
- Model: 2SH03006A
- Type: 3-position, 5-way (double solenoid)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.1–1.2 MPa (extended high-pressure capability)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 780g ±2% (with coil and connectors)
- Dimensions: 54mm(W) × 45mm(H) × 155mm(L) (including manifold interface)
- Seal materials: HNBR/FKM composite (oil and heat resistant)
- Temperature tolerance: -10℃ to 120℃ (with pulse-proof design)
- Flow capacity: 750L/min (ANR) at 0.5MPa
- Response time: ≤35ms (pressurized to full stroke)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Protection class: IP67 (submersible-ready with optional epoxy coating)
- Port thread depth: 12mm (aluminum alloy body)
Engineered for high-pressure pneumatic systems requiring precision sequencing, the 2SH03006A features a dual-coil latching design that maintains position without continuous power. Its stainless steel armature and reinforced PTFE seals enable operation in high-vibration environments with aggressive media (including synthetic lubricants). Includes manual override and position indicator window.
- Hydraulic press synchronization systems
- CNC machine tool clamping sequences
- Plastic injection molding machine actuators
- High-speed packaging line diverters
- Automotive brake testing rigs
- Offshore drilling equipment controls
Installation protocol:
Requires 20-30% duty cycle derating above 0.8MPa. Use M6 mounting screws with
vibration-damping washers. Maintain 1.5x port diameter clearance downstream
for optimal flow characteristics. Lubricate seals with ISO VG32-grade oil if
operating below -5℃.
| Property | Property Value |
|---|---|
| sku | 2SH03006A |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC12V |
