Airtac 2SH High Pressure Solenoid Valve 2SH05010FI
1. Direct-acting normally closed 2-port 2-position configuration, ensuring rapid and sensitive directional switching;
2. Extensive pressure range compatibility with model options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T);
3. Compact structure with minimized dimensions and lightweight design for convenient installation and maintenance;
4. SUS304 stainless steel body construction, B-class thermal-rated solenoid coil. Standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available through our technical department;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2SH
AirTAC 2SH05010FI High-Pressure Solenoid Valve Specifications
- Model: 2SH05010FI
- Type: 2-position, 5-port direct-acting (high-pressure series)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.5–10 MPa (72–1450 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 680g ±2% (including coil)
- Dimensions: 78mm(L) × 42mm(W) × 105mm(H)
- Valve body material: Anodized aluminum alloy (ISO-AlMg3)
- Seal material: Fluororubber (FKM) standard (NBR optional)
- Temperature range: -10℃ to 80℃ (FKM seals), -20℃ to 70℃ (NBR seals)
- Flow capacity: 850 L/min (ANR) at 0.5MPa
- Response time: ≤15ms (at rated voltage)
- Power consumption: 3.5W (DC), 5.5VA (AC)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
Industrial-grade high-pressure solenoid valve with hardened stainless steel spool and pressure-balanced design. Features shock-resistant construction with integrated surge suppression and manual override. Requires 10μm filtration (ISO 8573-1 class 4) for optimal performance. Compatible with compressed air, inert gases, and light hydraulic fluids (ISO VG32 or lower).
- Hydraulic power unit pressure control
- CNC punching machine tool changers
- High-pressure tire inflation systems
- Offshore drilling equipment actuators
- Industrial boiler safety venting systems
- Railway braking test benches
Installation requirements:
Mount in vibration-damped orientation (horizontal port alignment preferred).
Maintain minimum 20mm clearance around valve body for heat dissipation.
Use copper-free anti-seize compound on threads for pressures above 6MPa.
Requires 30-minute burn-in at 50% rated pressure before full operation.
| Property | Property Value |
|---|---|
| sku | 2SH05010FI |
| Port Size | PT3/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC12V |
