Airtac 2SH High Pressure Solenoid Valve 2SH05015BI
1. Direct-acting normally closed 2-port 2-position configuration, ensuring rapid and sensitive directional switching;
2. Extensive pressure range compatibility with model options: Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T);
3. Compact structure with minimized dimensions and lightweight design for convenient installation and maintenance;
4. SUS304 stainless steel body construction, B-class thermal-rated solenoid coil. Standard FPM (Fluororubber) seals compatible with multiple media. Custom seal materials available through our technical department;
5. IP65-rated coil protection with wiring options: direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AIRTAC | Series: 2SH
AirTAC 2SH05015BI High-Pressure Solenoid Valve Technical Details
- Model: 2SH05015BI
- Type: 5/2-way monostable (direct-acting)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.5–12 MPa (72–1,740 psi)
- Max working pressure: 15 MPa (burst pressure 22.5 MPa)
- Voltage variants: DC12V/24V ±10%, AC110V/220V ±10% 50/60Hz
- Power consumption: 3.5W (DC), 4.2VA (AC)
- Flow capacity: 750 L/min (Cv=1.8 at 0.5MPa)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal materials: HNBR main seals, FKM/Viton secondary seals
- Temperature range: -20℃ to 150℃ (with derating above 80℃)
- Fluid compatibility: Compressed air, inert gases (N2 required for O2 systems)
- Protection class: IP67 (dust/water resistant)
- Electrical connection: DIN43650 Form A with LED indicator
- Weight: 400g ±5% (excluding accessories)
- Dimensions: 75mm(L) × 45mm(W) × 85mm(H) (port centers 25mm spacing)
Industrial-grade high-pressure valve engineered for extreme pneumatic systems requiring precise directional control under sustained high loads. Features dual-coil thermal protection and shock-resistant brass body with electroless nickel plating. Includes manual override and position sensing readiness. Requires 10μm filtration (ISO 8573-1:2010 Class 3.4.2) with oil mist lubrication recommended.
- Hydraulic pump control in injection molding machines
- High-pressure gas charging systems (CNG/LPG)
- Industrial boiler safety shut-off mechanisms
- Test bench pressure cycling equipment
- Mining pneumatic drill rig controls
- Railway braking systems (requires EN 15085 certification)
Installation protocol:
Mount with vibration-damping brackets in high-shock environments.
Maintain minimum 20mm clearance from adjacent components for heat dissipation.
Always perform pressure decay test after installation (max 0.1 MPa/min drop at 10 MPa).
