Airtac 2SL Fluid Control Valve 2SL03006B
2、Wide pressure range compatibility, offering Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T) configurations;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation;
4、SUS304 stainless steel valve body, B-class heat-resistant solenoid coil, and FPM (Fluoroelastomer) standard seals compatible with multiple media. Custom seal materials available upon request - consult our technical department;
5、IP65-rated coil protection with wiring options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SL
AirTAC 2SL Series Fluid Control Valve 2SL03006B Technical Details
- Model: 2SL03006B
- Type: 3-position, 5-way closed center (pneumatic pilot operation)
- Port size: 1/4" NPT (G1/4 optional)
- Operating pressure: 0.05–1.0 MPa
- Max flow rate: 850 L/min (ANR)
- Voltage options: DC12V, DC24V, AC110V, AC220V (coil specifications vary)
- Weight: 480g ±2% (excluding accessories)
- Dimensions: 58mm(L) × 45mm(W) × 76mm(H) (manual override version adds 8mm)
- Seal material: HNBR rubber (FKM available for high-temp variants)
- Temperature range: -10℃ to 80℃ (extended to 120℃ with FKM seals)
- Response time: ≤50ms (at 0.5MPa)
- Protection rating: IP67 (coil)/IP40 (valve body)
- Interface: DIN43650 Form C connector
High-flow directional control valve with center-block function, featuring aluminum alloy body with hard anodized treatment for corrosion resistance. The dual-pressure pilot design ensures stable switching under fluctuating line pressures. Requires 5μm filtered air with lubrication (ISO 8573-1 class 4). Compatible with vacuum applications when paired with vacuum-rated seals.
- Plastic injection molding machine clamp control
- Automated assembly line cylinder sequencing
- Textile machinery pneumatic circuits
- Semiconductor wafer handling systems
- Food processing equipment (NSF-compliant versions available)
Maintenance tip:
Perform monthly cycling tests under load to prevent spool sticking.
Use only AirTAC-approved silicone grease (ASG-04) for seal lubrication.
- Manual override: Optional side-mounted lever (2SL03006B-M)
- Position detection: Built-in inductive sensor slots
- Mounting: Panel mount or sub-base (ISO 5599-1 compatible)
| Property | Property Value |
|---|---|
| sku | 2SL03006B |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC24V |
