Airtac 2SL Fluid Control Valve 2SL03006BI
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Wide pressure range compatibility, offering Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T) configurations;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation;
4、SUS304 stainless steel valve body, B-class heat-resistant solenoid coil, and FPM (Fluoroelastomer) standard seals compatible with multiple media. Custom seal materials available upon request - consult our technical department;
5、IP65-rated coil protection with wiring options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SL
AirTAC 2SL03006BI Fluid Control Valve Technical Details
- Model: 2SL03006BI
- Type: 5/3-way closed center (solenoid pilot-operated)
- Port size: G1/8 (ISO228-1 standard)
- Operating pressure range: 0.1–1.0 MPa
- Maximum flow rate: 750 L/min (ANR)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 480g ±5% (with connectors)
- Dimensions: 98mm(L) × 45mm(W) × 75mm(H) (excluding mounting brackets)
- Seal material: FKM (Fluorocarbon Rubber) standard (NBR optional)
- Ambient temperature: -20℃ to 80℃ (non-freezing)
- Response time: ≤15ms (at 0.5MPa)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Protection class: IP67 (dust/water resistant)
- Port thread depth: 10mm (minimum engagement)
High-performance mid-size directional control valve featuring dual solenoid activation and manual override. The hardened aluminum alloy body with chrome-plated brass core ensures durability in high-cycle applications. Optimized flow paths reduce pressure drop by 18% compared to previous generation models. Requires 5μm filtration (40μm for emergency use). Compatible with ISO 15407-1 standards.
- Pneumatic cylinder sequencing in assembly lines
- Vacuum generator control in packaging machinery
- Coolant flow regulation for CNC machining centers
- Bidirectional actuator control in material handling systems
- Process valve automation in food-grade equipment
Installation guidelines:
Mount horizontally with arrow indicating flow direction. Maintain minimum 15mm clearance for heat dissipation.
Lubricate sliding parts with ISO VG32 pneumatic oil monthly in continuous operation. Use copper-free anti-seize compound on threads.
Critical note:
Not compatible with phosphate ester fluids or chlorine-based lubricants.
Always install downstream moisture separator when used in humid environments.
| Property | Property Value |
|---|---|
| sku | 2SL03006BI |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | DC24V |
