Airtac 2SL Fluid Control Valve 2SL03008A
2、Wide pressure range compatibility, offering Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T) configurations;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation;
4、SUS304 stainless steel valve body, B-class heat-resistant solenoid coil, and FPM (Fluoroelastomer) standard seals compatible with multiple media. Custom seal materials available upon request - consult our technical department;
5、IP65-rated coil protection with wiring options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SL
AirTAC 2SL Series Fluid Control Valve 2SL03008A Technical Details
- Model: 2SL03008A
- Type: 3-position, 5-way closed center (double solenoid)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure: 0.05–1.0 MPa (7-145 PSI)
- Flow capacity: 750 L/min (Cv=1.2 at 0.5MPa)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Response time: ≤25ms (excitation), ≤35ms (reset)
- Weight: 480g ±5% (with connectors)
- Dimensions: 72mm(L) × 54mm(W) × 85mm(H) (excluding fittings)
- Body material: Anodized aluminum alloy (ADC12)
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Power consumption: 2.8W (DC), 4.5VA (AC)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional control valve with dual-coil latching design, featuring manual override and position detection switch compatibility. Optimized spool geometry reduces pressure drop by 18% compared to previous generation. Requires filtered compressed air (5-50μm) with lubricator (ISO VG32 recommended).
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- CNC tool changers with position feedback
- Food packaging equipment requiring frequent cycling
- Semiconductor wafer handling robots
Maintenance protocol:
Perform monthly air purge (3-second pulse every 500,000 cycles) to prevent
spool sticking. Use only compatible grease (AirTAC PG-7 specification) for
manual override mechanism.
| Property | Property Value |
|---|---|
| sku | 2SL03008A |
| Port Size | PT1/4 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC220V |
