Airtac 2SL Fluid Control Valve 2SL05010AI
2、Wide pressure range compatibility, offering Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T) configurations;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation;
4、SUS304 stainless steel valve body, B-class heat-resistant solenoid coil, and FPM (Fluoroelastomer) standard seals compatible with multiple media. Custom seal materials available upon request - consult our technical department;
5、IP65-rated coil protection with wiring options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SL
AirTAC 2SL05010AI Fluid Control Valve Specifications
- Model: 2SL05010AI
- Type: 5/2-way single solenoid spring return (direct-acting)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10% tolerance)
- Flow capacity: 850 l/min (Cv=1.2)
- Response time: ≤15ms (energized), ≤20ms (de-energized)
- Weight: 320g ±5% (without connector)
- Dimensions: 58mm(L) × 34mm(W) × 72mm(H)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 60℃ (no freezing)
- Power consumption: 2.5W (DC), 3.2VA (AC)
- Protection rating: IP67 (dustproof & temporary immersion)
- Port thread depth: 12mm (minimum engagement required)
High-flow proportional control valve with zero-pressure start capability, featuring brass body construction with hard-anodized aluminum solenoid housing. Designed for rapid cycling applications requiring precise directional control. Includes manual override button for system diagnostics. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.2.3 air quality.
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- Textile machinery tension control
- Semiconductor wafer handling robots
- Food processing pneumatic circuits (oil-free version available)
Installation Best Practices:
Mount with vibration-damping brackets in high-frequency operation environments.
Use Teflon tape on male threads only, leaving 1.5 thread turns exposed.
Lubricate seals with ISO VG32 pneumatic oil if used in continuous duty cycles.
Avoid pressure shocks exceeding 1.2 MPa. Install surge suppressor upstream
if system contains compressors with cyclic loading. Not recommended for
vacuum applications below -0.3 bar.
| Property | Property Value |
|---|---|
| sku | 2SL05010AI |
| Port Size | PT3/8 |
| Flow Aperture | 7mm |
| Coil Voltage | AC220V |
