Airtac 2SL Fluid Control Valve 2SL05010B
2、Wide pressure range compatibility, offering Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Extra-large flow (T) configurations;
3、Compact design with minimized footprint, lightweight construction, and tool-free installation;
4、SUS304 stainless steel valve body, B-class heat-resistant solenoid coil, and FPM (Fluoroelastomer) standard seals compatible with multiple media. Custom seal materials available upon request - consult our technical department;
5、IP65-rated coil protection with wiring options: Direct lead wire or DIN connector.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2SL
AirTAC 2SL05010B Fluid Control Valve Specifications
- Model: 2SL05010B
- Type: 5/2-way single solenoid pilot-operated valve
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V, DC24V, AC110V, AC220V (±10% tolerance)
- Weight: 350g ±5% (including coil)
- Dimensions: 85mm(L) × 35mm(W) × 60mm(H)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -20℃ to 70℃ (non-freezing conditions)
- Power consumption: ≤2.5W (DC models), ≤3.5VA (AC models)
- Flow capacity: 750 L/min (ANR) at 0.5 MPa
- Response time: ≤30ms (energize), ≤50ms (de-energize)
- Protection rating: IP67 (coil), IP40 (valve body)
- Port thread depth: 10mm (minimum engagement)
High-flow directional control valve with manual override capability, featuring a reinforced polyamide body for chemical resistance. The optimized spool design reduces air consumption by 15% compared to previous generations. Includes LED status indicator and surge protection circuitry. Requires 5μm filtered lubricated air (ISO 8573-1 Class 3.4.2).
- Automated production line actuators
- Plastic injection molding machine clamp systems
- Food processing pneumatic circuits (FDA-compliant versions available)
- Automotive tire assembly equipment
- Medical gas control systems (special material option)
Installation guidelines:
Mount in vibration-free environments below 10Hz. Use M5 mounting screws with 0.4-0.6Nm torque.
For horizontal installation, orient exhaust ports downward. Lubricate monthly with ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | 2SL05010B |
| Port Size | PT3/8 |
| Flow Aperture | 7mm |
| Coil Voltage | DC24V |
