Airtac 2V Fluid Control Valve 2V025-08-A
1. Direct-acting normally closed 2-port 2-position solenoid valve with rapid and responsive switching characteristics;
2. Lightweight and compact structural design;
3. Features brass valve body construction, Class B thermal-rated electromagnetic coil, and fluorinated rubber (VITON) seals compatible with multiple media types;
2V130/250 Series
1. Diaphragm pilot-operated 2-port 2-position solenoid valve offering low power consumption and high flow capacity;
2. Low cracking pressure requirement with minimum operating pressure differential of 0.05MPa;
3. Constructed with brass valve body, Class B thermal-rated electromagnetic coil, and Nitrile Butadiene Rubber (NBR) sealing components;
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2V
AirTAC 2V025-08-A Fluid Control Valve Specifications
- Model: 2V025-08-A
- Type: 2-position 2-way normally closed (direct-acting)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±15%), AC220V (±15%)
- Coil class: Class F (155℃) insulation
- Weight: 0.8 kg (1.76 lbs)
- Dimensions: 80mm(L) × 60mm(W) × 120mm(H)
- Seal material: HNBR rubber (improved heat/oil resistance)
- Temperature range: -5℃ to 80℃ (operating fluid), -20℃ to 60℃ (ambient)
- Response time: ≤20ms (at rated voltage)
- Protection rating: IP67 (coil), IP40 (valve body)
- Flow capacity: CV 0.65 (Kv 0.57)
- Port thread depth: 12mm (minimum engagement)
High-flow compact solenoid valve with reinforced epoxy-coated coil for chemical resistance. Features manual override button for system debugging and emergency control. Optimized spool design reduces pressure drop by 18% compared to previous generation models. Requires ISO 8573-1:2010 Class 3.4.2 compressed air (max 5μm particle size).
- Industrial pneumatic clamping systems
- Beverage filling line pressure regulation
- Plastic injection molding machine actuators
- Semiconductor wafer handling robotics
- CNC machine tool pneumatic circuits
Installation note:
For horizontal mounting, install downstream filter regulator within 500mm.
Lubricated air requires 1-2 drops of ISO VG32 oil per m³ airflow.
Avoid rapid cycling (>5Hz) without consulting technical support.
| Property | Property Value |
|---|---|
| sku | 2V025-08-A |
| Port Size | PT1/4 |
| Flow Aperture | <2.5 mm> |
| Coil Voltage | AC220V |
