Airtac 2V Fluid Control Valve 2V02506E
1. Direct-acting normally closed 2-port 2-position solenoid valve with rapid and responsive switching characteristics;
2. Lightweight and compact structural design;
3. Features brass valve body construction, Class B thermal-rated electromagnetic coil, and fluorinated rubber (VITON) seals compatible with multiple media types;
2V130/250 Series
1. Diaphragm pilot-operated 2-port 2-position solenoid valve offering low power consumption and high flow capacity;
2. Low cracking pressure requirement with minimum operating pressure differential of 0.05MPa;
3. Constructed with brass valve body, Class B thermal-rated electromagnetic coil, and Nitrile Butadiene Rubber (NBR) sealing components;
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2V
AirTAC 2V02506E Fluid Control Valve Technical Details
- Model: 2V02506E
- Type: 2-position 5-way direct-acting solenoid valve
- Port configuration: 5/2-way (double solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.1–1.0 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Max flow rate: 850 L/min (ANR)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Seal material: Heat-resistant NBR (Nitrile) with PTFE coating
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Fluid temperature: 0℃ to 60℃
- Protection class: IP67 (dustproof & waterproof)
- Weight: 480g ±5%
- Dimensions: 76mm(L) × 42mm(W) × 68mm(H)
- Mounting type: Direct piping or sub-base (ISO G1/4 compatible)
High-flow proportional control valve with dual solenoid activation, featuring rapid cycling capability (up to 5Hz) and low hysteresis. The aluminum alloy body with hard anodizing resists chemical corrosion, while the PTFE-coated seals ensure leak-free operation in high-cycle applications. Requires 5μm filtration (40μm for emergency use).
- Automated assembly line cylinder sequencing
- Plastic injection molding machine ejectors
- Textile machinery tension control systems
- Automotive brake testing equipment
- Food packaging vacuum/pressure switching
Installation protocol:
Mount with vibration-damping brackets in high-frequency applications.
Lubricate using ISO VG32 turbine oil if pneumatic system lacks lubricator.
Allow 15mm clearance below valve for condensate drainage.
| Property | Property Value |
|---|---|
| sku | 2V02506E |
| Port Size | PT1/8 |
| Flow Aperture | <2.5 mm> |
| Coil Voltage | AC24V |
