Airtac 2V Fluid Control Valve 2V02506F
1. Direct-acting normally closed 2-port 2-position solenoid valve with rapid and responsive switching characteristics;
2. Lightweight and compact structural design;
3. Features brass valve body construction, Class B thermal-rated electromagnetic coil, and fluorinated rubber (VITON) seals compatible with multiple media types;
2V130/250 Series
1. Diaphragm pilot-operated 2-port 2-position solenoid valve offering low power consumption and high flow capacity;
2. Low cracking pressure requirement with minimum operating pressure differential of 0.05MPa;
3. Constructed with brass valve body, Class B thermal-rated electromagnetic coil, and Nitrile Butadiene Rubber (NBR) sealing components;
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2V
AirTAC 2V02506F Fluid Control Valve Technical Details
- Model: 2V02506F
- Type: 2-position 3-way (normally closed, spring return)
- Port configuration: 1/4" NPT (G1/8 optional)
- Operating pressure range: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 750 l/min (Cv=1.3 at 0.5 MPa)
- Response time: ≤15ms (actuation), ≤20ms (release)
- Weight: 280g ±5g (with coil)
- Dimensions: 56mm(L) × 45mm(W) × 70mm(H) (excluding ports)
- Seal materials: NBR (standard), optional Viton for high-temp
- Ambient temperature: -5℃ to 80℃ (NBR), -5℃ to 120℃ (Viton)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Protection class: IP67 (coil), IP40 (valve body)
- Port thread depth: 10mm (NPT), 8.5mm (G)
High-flow proportional control valve with brass body construction and reinforced Teflon piston rings. Features manual override capability via push-button actuator and surge protection circuitry. Requires 5μm filtration (40μm max particle size) with lubricated or non-lubricated air. Compatible with vacuum applications when paired with EPDM seals (optional).
- Pneumatic cylinder sequencing in assembly lines
- Vacuum pick-and-place systems
- Textile machinery air flow control
- Beverage dispensing systems
- Semiconductor wafer handling equipment
- Automotive brake testing rigs
Installation guidelines:
Mount in vibration-free environment with 15mm minimum clearance below for condensate drainage.
Use copper-free anti-seize compound on threads. Cycle valve 5x manually before power connection
to seat seals properly. Maximum allowable leakage: 30 cm³/min at 0.5 MPa.
| Property | Property Value |
|---|---|
| sku | 2V02506F |
| Port Size | PT1/8 |
| Flow Aperture | <2.5 mm> |
| Coil Voltage | DC12V |
