Airtac 2V Fluid Control Valve 2V02508-X0
1. Direct-acting normally closed 2-port 2-position solenoid valve with rapid and responsive switching characteristics;
2. Lightweight and compact structural design;
3. Features brass valve body construction, Class B thermal-rated electromagnetic coil, and fluorinated rubber (VITON) seals compatible with multiple media types;
2V130/250 Series
1. Diaphragm pilot-operated 2-port 2-position solenoid valve offering low power consumption and high flow capacity;
2. Low cracking pressure requirement with minimum operating pressure differential of 0.05MPa;
3. Constructed with brass valve body, Class B thermal-rated electromagnetic coil, and Nitrile Butadiene Rubber (NBR) sealing components;
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2V
AirTAC 2V025-08-X0 Fluid Control Valve Technical Specifications
- Model: 2V025-08-X0 (2V02508-X0)
- Valve type: 5-port 2-position directional valve
- Port configuration: 2 exhaust ports, 2 outlet ports, 1 supply port
- Port size: PT1/4 (G1/8 optional)
- Operating pressure range: 0.2–0.8 MPa (29–116 PSI)
- Max flow capacity: 850 l/min (Cv=1.2)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤15ms (at rated voltage)
- Seal material: Nitrile rubber (NBR) standard, optional Viton (FKM)
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Weight: 320g ±5% (including coil)
- Dimensions: 70mm(L) × 35mm(W) × 50mm(H)
- Mounting pattern: ISO 5599-1 standard
- Protection rating: IP67 (coil), IP40 (valve body)
- Service life: ≥10 million cycles (at 0.5 MPa)
High-flow solenoid valve with optimized spool design for rapid switching in pneumatic systems. Features dual-pressure operation capability and shock-resistant brass construction. The pilot-operated mechanism ensures reliable actuation even under pressure fluctuations. Requires 5μm filtered air with lubrication (ISO 8573-1 class 4.4.3).
- Automated packaging line cylinder control
- Plastic injection molding machine actuators
- Conveyor system diverters
- Automotive assembly tooling
- CNC machine tool clamping systems
Installation guidelines:
Mount horizontally with ports downward to prevent debris accumulation.
Use M5x12 mounting screws (2.5N·m torque limit). Maintain minimum 15mm
clearance around exhaust ports for proper venting.
| Property | Property Value |
|---|---|
| sku | 2V02508-X0 |
| Port Size | PT1/4 |
| Flow Aperture | <2.5 mm> |
| Coil Voltage | DC24V |
