Airtac 2V Fluid Control Valve 2V02508E
1. Direct-acting normally closed 2-port 2-position solenoid valve with rapid and responsive switching characteristics;
2. Lightweight and compact structural design;
3. Features brass valve body construction, Class B thermal-rated electromagnetic coil, and fluorinated rubber (VITON) seals compatible with multiple media types;
2V130/250 Series
1. Diaphragm pilot-operated 2-port 2-position solenoid valve offering low power consumption and high flow capacity;
2. Low cracking pressure requirement with minimum operating pressure differential of 0.05MPa;
3. Constructed with brass valve body, Class B thermal-rated electromagnetic coil, and Nitrile Butadiene Rubber (NBR) sealing components;
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2V
AirTAC 2V02508E 2-Position 5-Port Fluid Control Valve Specifications
- Model: 2V02508E
- Type: 2-position 5-way, double solenoid operated
- Port configuration: P (pressure), A/B (actuator ports), R/S (exhaust)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Body material: Anodized aluminum alloy
- Seal material: Heat-resistant NBR (Nitrile) with PTFE backup rings
- Ambient temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Response time: ≤20ms (at 0.5MPa)
- Flow capacity: CV 1.8 / Kv 1.56 (at 0.5MPa)
- Weight: 650g ±5% (including coils)
- Dimensions: 75mm(L) × 50mm(W) × 45mm(H)
- Mounting: ISO 5599-1 standard subplate
- Protection class: IP67 (coils), IP40 (valve body)
- Compliance: RoHS, ISO 15407-1, CE
High-speed directional control valve with dual manual override options (push-pull/padlockable). Features pressure-balanced spool design for low power consumption (2.2W typical) and zero pressure differential operation. The hard-anodized body resists chemical corrosion in humid environments. Includes LED status indicators and surge protection circuitry.
- Bi-directional pneumatic cylinder control in assembly lines
- Clamping/unclamping sequences in CNC machinery
- Pneumatic gripper actuation in robotics
- Material handling systems requiring rapid cycling (>5Hz)
- Vacuum generator switching in packaging equipment
Installation guidelines:
Use ISO 5599-1 compliant subplate (cleaned with non-residue solvent).
Maintain 0.5m minimum clearance from high-frequency inverters.
Lubricate with ISO VG32 turbine oil if air line isn't pre-lubricated.
| Property | Property Value |
|---|---|
| sku | 2V02508E |
| Port Size | PT1/4 |
| Flow Aperture | <2.5 mm> |
| Coil Voltage | AC24V |
