Airtac 2V Fluid Control Valve 2V02508F
1. Direct-acting normally closed 2-port 2-position solenoid valve with rapid and responsive switching characteristics;
2. Lightweight and compact structural design;
3. Features brass valve body construction, Class B thermal-rated electromagnetic coil, and fluorinated rubber (VITON) seals compatible with multiple media types;
2V130/250 Series
1. Diaphragm pilot-operated 2-port 2-position solenoid valve offering low power consumption and high flow capacity;
2. Low cracking pressure requirement with minimum operating pressure differential of 0.05MPa;
3. Constructed with brass valve body, Class B thermal-rated electromagnetic coil, and Nitrile Butadiene Rubber (NBR) sealing components;
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2V
AirTAC 2V02508F Fluid Control Valve Specifications
- Model: 2V02508F
- Type: 5/2-way double solenoid (spring return optional)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage options: DC12V, DC24V, AC110V 50/60Hz, AC220V 50/60Hz
- Flow capacity: 750 l/min (Cv=1.2 at 0.5MPa)
- Response time: ≤15ms (exhaust to actuation)
- Weight: 235g ±5g (with connectors)
- Dimensions: 58mm(L) × 36mm(W) × 74mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) for improved oil resistance
- Temperature range: -10℃ to 80℃ (non-freezing operation)
- Power consumption: 2.5W (DC), 3.2VA (AC)
- Protection rating: IP67 (dustproof & temporary immersion)
- Port thread depth: 10mm (minimum engagement)
High-flow bistable valve with dual coil redundancy, featuring manual override and position sensing capability. The aluminum alloy body with hard anodized treatment ensures durability in humid environments. Requires 5μm filtration (40μm for basic operations) and lubricated air (ISO VG32 grade recommended).
- Automated assembly line clamping systems
- Plastic injection molding machine ejectors
- CNC tool changers with position feedback
- Food processing pneumatic circuits (non-contact areas)
- Electric vehicle battery cooling systems
Installation guidelines:
Mount with M4 screws (max torque 1.2N·m). Maintain 15mm clearance
below valve for condensate drainage. Use shielded cables when
installed near frequency inverters. Cycle rate ≤5Hz for optimal
coil lifespan.
| Property | Property Value |
|---|---|
| sku | 2V02508F |
| Port Size | PT1/4 |
| Flow Aperture | <2.5 mm> |
| Coil Voltage | DC12V |
