Airtac 2V Fluid Control Valve 2V02508FI
1. Direct-acting normally closed 2-port 2-position solenoid valve with rapid and responsive switching characteristics;
2. Lightweight and compact structural design;
3. Features brass valve body construction, Class B thermal-rated electromagnetic coil, and fluorinated rubber (VITON) seals compatible with multiple media types;
2V130/250 Series
1. Diaphragm pilot-operated 2-port 2-position solenoid valve offering low power consumption and high flow capacity;
2. Low cracking pressure requirement with minimum operating pressure differential of 0.05MPa;
3. Constructed with brass valve body, Class B thermal-rated electromagnetic coil, and Nitrile Butadiene Rubber (NBR) sealing components;
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2V
AirTAC 2V025-08FI Fluid Control Valve Technical Specifications
- Model: 2V025-08FI
- Type: 2-position 5-way pilot-operated solenoid valve
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage variants: DC12V/24V, AC110V/220V (±10% tolerance)
- Weight: 480g ±5% (including coil)
- Dimensions: 58mm(W) × 46mm(H) × 135mm(L)
- Flow capacity: 750 NL/min (ANR, at 0.5 MPa)
- Seal materials: HNBR main seals with FKM backup rings
- Temperature tolerance: -5℃ to 80℃ (non-freezing)
- Response time: ≤25ms (energize), ≤35ms (de-energize)
- Protection class: IP67 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with dual-pressure capability, featuring anti-vibration brass core and dual-chamber pilot design for reliable operation in high-cycle applications. The encapsulated coil resists hydraulic fluid penetration, making it suitable for hybrid pneumatic-hydraulic systems. Requires 25μm filtration recommended.
- Automated assembly line clamping/unclamping mechanisms
- Plastic injection molding machine ejectors
- CNC tool changers with pneumatic tool locking
- Beverage filling systems requiring rapid cylinder reversal
- Textile machinery tension control subsystems
Installation protocol:
Mount with manifold base using M5×16mm screws (2.5N·m torque).
Maintain horizontal piping orientation to prevent condensate pooling.
Allow 20mm side clearance for heat dissipation during continuous operation.
| Property | Property Value |
|---|---|
| sku | 2V02508FI |
| Port Size | PT1/4 |
| Flow Aperture | <2.5 mm> |
| Coil Voltage | DC12V |
