Airtac 2V Fluid Control Valve 2V13010B
1. Direct-acting normally closed 2-port 2-position solenoid valve with rapid and responsive switching characteristics;
2. Lightweight and compact structural design;
3. Features brass valve body construction, Class B thermal-rated electromagnetic coil, and fluorinated rubber (VITON) seals compatible with multiple media types;
2V130/250 Series
1. Diaphragm pilot-operated 2-port 2-position solenoid valve offering low power consumption and high flow capacity;
2. Low cracking pressure requirement with minimum operating pressure differential of 0.05MPa;
3. Constructed with brass valve body, Class B thermal-rated electromagnetic coil, and Nitrile Butadiene Rubber (NBR) sealing components;
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2V
AirTAC 2V13010B Fluid Control Valve Technical Specifications
- Model: 2V13010B
- Type: 2-position 2-way direct-acting solenoid valve
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V, DC24V, AC110V(50/60Hz), AC220V(50/60Hz)
- Flow coefficient (Cv): 1.2
- Response time: ≤15ms (open/close)
- Weight: 310g ±5% (with connector)
- Dimensions: 76mm(L) × 34mm(W) × 88mm(H)
- Seal material: HNBR rubber (high nitrile for oil resistance)
- Temperature range: -20℃ to 80℃ (with intermittent peak at 100℃)
- Power consumption: 1.6W (DC), 3.5VA (AC)
- Protection rating: IP67 (dustproof/water immersion resistant)
- Port thread depth: 12mm (with O-ring groove)
High-flow solenoid valve with reinforced armature system, featuring 30% faster response than standard models. The brass body with electroless nickel plating ensures corrosion resistance in humid environments. Designed for continuous duty cycles up to 1 million operations. Requires 5μm filtration (25μm max) with lubricated or non-lubricated air.
- Plastic injection molding machine cylinder control
- CNC pneumatic tool changers
- Beverage filling line actuators
- Textile machinery air jet looms
- Railway brake system pilot valves
Installation guidelines:
Mount with 10mm minimum clearance on all sides. Use M4×12 screws
(1.2N·m torque). For horizontal mounting, orient coil upward.
Always install downstream of pressure regulator. Lubricate O-rings
with silicone grease (Parker O-Lube 111 recommended).
| Property | Property Value |
|---|---|
| sku | 2V13010B |
| Port Size | PT3/8 |
| Flow Aperture | 13mm |
| Coil Voltage | DC24V |
