Airtac 2WH High-Pressure Solenoid Valve 2WH05015AIG
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH05015AIG High-Pressure Solenoid Valve Specifications
- Model: 2WH05015AIG
- Type: 5-port/3-position closed center (pilot-operated)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure: 0.3–16 MPa (30-160 bar)
- Max pressure: 20 MPa (200 bar)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±15%), AC220V (±15%)
- Coil insulation class: Class F (155℃)
- Weight: 1.25 kg (2.76 lbs) with coil
- Dimensions: 140mm(L) × 55mm(W) × 108mm(H)
- Port pitch: 30mm between ports
- Seal material: Fluororubber (FKM) for high temp/pressure
- Temperature range: -10℃ to 150℃ (with FKM seals)
- Power consumption: 4.5W (AC), 3.5W (DC)
- Response time: ≤15ms (at 20℃)
- Protection rating: IP67 (coil), IP65 (valve body)
- Flow coefficient (Cv): 2.4 (Kv: 2.08)
- Max operating viscosity: 200 cSt
Heavy-duty high-pressure solenoid valve engineered for extreme industrial environments. Features triple-sealed construction with hardened stainless steel spool and anti-vibration coil design. Rated for 1 million cycles minimum at max pressure. Requires 10μm filtration with ISO 8573-1:2010 Class 3.4.3 compressed air (max oil content 1mg/m³).
- Hydraulic system pilot controls
- High-pressure pneumatic presses (300+ ton)
- CNC machine tool clamping systems
- Offshore drilling equipment controls
- Steel mill blast furnace actuators
- High-speed stamping machinery
Installation requirements:
Must be mounted horizontally with arrow aligned to flow direction.
Requires 20mm clearance below valve for spool maintenance.
Use Loctite 243 on mounting threads.
Initial 50-hour run-in period requires weekly lubrication (ISO VG32 oil mist).
| Property | Property Value |
|---|---|
| sku | 2WH05015AIG |
| Port Size | PT 1/2 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC220V |
