Airtac 2WL High Pressure Solenoid Valve 2WL03006CI
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Wide pressure range adaptability: Available in Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced dimensions and lightweight construction for easy installation/maintenance;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluorocarbon Rubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector.
Category: High Pressure Solenoid Valves | Brand: Airtac | Series: 2WL
AirTAC 2WL03006CI High-Pressure Solenoid Valve Specifications
- Model: 2WL03006CI
- Type: 2-position, 3-way normally closed (direct-acting)
- Port size: G3/8 (BSPP thread)
- Operating pressure: 0.1–25 MPa (extended high-pressure design)
- Max working pressure: 31.5 MPa (burst pressure 63 MPa)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Power consumption: 5.5W (DC), 6.5VA (AC)
- Response time: ≤15ms (at 20℃)
- Seal material: HNBR + FKM (high-pressure resistant compound)
- Temperature range: -20℃ to 80℃ (with ≤95% RH)
- Flow rate: 850 L/min (ANR at 0.5MPa)
- Weight: 520g ±5% (without connector)
- Dimensions: 82mm(L) × 50mm(W) × 64mm(H) (manual override protrusion included)
- Protection rating: IP67 (dustproof & temporary immersion)
- Port alignment: ISO 5599-1 standard (interchangeable with competitor models)
Industrial-grade high-pressure solenoid valve engineered for extreme hydraulic and pneumatic systems. Features triple-layer epoxy-coated body with hardened stainless steel core components. The direct-acting design ensures reliable operation without minimum pressure requirements. Integrated manual override allows emergency control during power outages.
- Hydraulic press emergency stop systems
- CNC machine tool coolant control
- High-pressure gas chromatography equipment
- Industrial boiler safety venting mechanisms
- Offshore drilling platform pneumatic controls
- Automated pressure testing rigs (up to 2500 PSI)
Installation guidelines:
Mount with vibration-damping brackets in high-shock environments.
Use reinforced PTFE tubing for pressure lines above 15 MPa.
Always install downstream 5μm filter (not included).
For vertical mounting, position coil assembly upward to prevent debris accumulation.
Critical note:
Requires 2-second minimum interval between continuous operations at max pressure.
Use locknuts with 18-22 N·m torque for port connections.
Not compatible with phosphate ester hydraulic fluids.
| Property | Property Value |
|---|---|
| sku | 2WL03006CI |
| Port Size | PT1/8 |
| Flow Aperture | <4mm> |
| Coil Voltage | AC 110V |
