Airtac 2WL High Pressure Solenoid Valve 2WL05010BI
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Wide pressure range adaptability: Available in Ultra-High Pressure (X), High Pressure (H), Standard, Large Flow (L), and Extra-Large Flow (T) configurations;
3. Compact design with reduced dimensions and lightweight construction for easy installation/maintenance;
4. Brass valve body with Class B thermal-rated coil. Standard FPMF (Fluorocarbon Rubber) seals compatible with multiple media. Custom seal materials available upon consultation with technical department;
5. IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector.
Category: High Pressure Solenoid Valves | Brand: Airtac | Series: 2WL
AirTAC 2WL High Pressure Solenoid Valve 2WL05010BI Technical Details
- Model: 2WL05010BI
- Type: 2-position 5-way direct acting (monostable)
- Port size: G1/4 (ISO 228/1 standard)
- Operating pressure: 0.5–21 MPa (72.5–3045 PSI)
- Voltage options: DC24V (±10%), AC220V 50/60Hz
- Max flow rate: 1,800 NL/min (ANR, at 0.5MPa)
- Weight: 850g ±2% (with coil)
- Dimensions: 120mm(L) × 60mm(W) × 65mm(H)
- Body material: Anodized aluminum alloy (AL6063-T5)
- Seal material: Fluorocarbon rubber (FKM) for high temp/pressure
- Temperature range: -5℃ to 80℃ (non-freezing)
- Response time: ≤10ms (at rated voltage)
- Protection rating: IP67 (coil), IP40 (valve body)
- Coil class: Class F (155℃) insulation
- Power consumption: 10W (AC), 8.5W (DC)
- Port thread depth: 12mm (minimum engagement)
High-pressure industrial solenoid valve with hardened stainless steel spool and multi-layer piston seals. Features zero-pressure differential start capability and surge protection circuitry. Designed for continuous duty cycles up to 1 million operations. Requires 5μm filtration (40μm for emergency use).
- Hydraulic system pilot controls
- CNC machine tool clamping mechanisms
- High-pressure gas booster systems
- Plastic injection molding machines
- Compressed natural gas (CNG) stations
- Pressure vessel testing equipment
Installation requirements:
Mount vertically (±15° tolerance) with flow arrow alignment.
Use anti-vibration mounts in applications exceeding 15Hz.
Apply 242 Loctite on pipe threads and torque to 15-20N·m.
Allow 30-minute burn-in at 50% pressure before full operation.
| Property | Property Value |
|---|---|
| sku | 2WL05010BI |
| Port Size | PT3/8 |
| Flow Aperture | 7mm |
| Coil Voltage | DC24V |
